Collar CONDUR Ø40 4033040 ISR KOUVIDIS

Features:

• Secure attachment of all KOUVIDIS pipes, rigid and flexible.
• Part of the pipe systems for the protection and management of cables CONDUR – CONFLEX, MEDISOL – MEDIFLEX, SILCOR – SIFLEX, CONDUR HF – CONFLEX HF, MEDISOL HF – MEDIFLEX HF.
• Built-in ecological rodent repellent.
• Patented rodent protection by the European Patent Office and the OBI.

APPLICATION FIELD: Intended for surface electrical installations.

APPLICATION STANDARD: EN 61386.01, EN 50642

CONFORMITY DIRECTIVES: 2014/35/EU (LVD), 2011/65/EU (RoHS)

COLOR: RAL 7035 Light gray

NOMINAL DIAMETER: Based on outer diameter (DN/OD)

Properties:

• Minimum application temperature: -25°C
• Maximum application temperature: +120°C
• Electrical properties with insulation characteristics.
• Resistance to flame spread: Does not spread the flame.

Additional characteristics:

• Raw material: Specially stabilized halogen-free and heavy metal-free thermoplastic PC (RoHS).
• Resistance to aging: Resistant to solar radiation (UV).
• Halogen-free: Does not emit toxic or corrosive gases in case of fire.
• Antistatic technology: Protection against static electricity.

RECOMMENDED APPLICATION FIELD TECHNICAL CHARACTERISTICS:

• Ø16 4003016 15.8 35 4×50 3400
• Ø20 4003020 19.8 40 4×50 2000
• Ø25 4003025 24.8 46 4×30 1920
• Ø32 4003032 31.8 53 30 1440
• Ø40 4003040 39.8 63 20 960
• Ø50 4003050 49.8 74 20 960
• Ø63 4003063 62.8 88 20 960
