Collar CONDUR Ø20 ISR 4033020 KOUVIDIS

Features:

• Designed for surface electrical installations.
• APPLICATION STANDARD: EN 61386.01, EN 50642
• COMPLIANCE DIRECTIVES: 2014/35/EU (LVD), 2011/65/EU (RoHS)
• COLOR: RAL 7035 Light Grey
• NOMINAL DIAMETER: Based on external diameter (DN/OD)
• Suitable for all series of Heavy (1250Nt), Medium (750Nt), and Light (320Nt) type systems, as well as the corresponding halogen-free series.
• Does not emit toxic or corrosive gases in case of fire.
• The recommended distance between collars is 50cm for vertical installations and 40cm for horizontal installations.
• Installed using plug and 4mm screw.
• It has side notches for easy assembly on a rail.
• Not attractive as food for rodents (European Patent EP2698792).
• Incorporates antistatic technology that provides protection against static electricity (Patent Protected: 1009810).

Properties:

• Minimum application temperature: -25°C
• Maximum application temperature: +120°C
• Electrical properties with electrical insulation characteristics.
• Resistance to flame spread: Does not propagate flame.
• Raw material: Specially stabilized halogen-free thermoplastic PC and heavy metal free (RoHS).
• Aging resistance: Resistant to solar radiation (UV).
• Halogen-free: Does not emit toxic or corrosive gases in case of fire.
• Antistatic Technology: Protection against static electricity.

RECOMMENDED APPLICATION FIELD TECHNICAL CHARACTERISTICS:

• Type  Code   Ø16 4003016 15.8 35 4×50 3400
• Ø20 4003020 19.8 40 4×50 2000
• Ø25 4003025 24.8 46 4×30 1920
• Ø32 4003032 31.8 53 30 1440
• Ø40 4003040 39.8 63 20 960
• Ø50 4003050 49.8 74 20 960
• Ø63 4003063 62.8 88 20 960
