Dimensions

Power

550 W

Size

ATX, EPS

Size

Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

ATX

The most common power supply size, compatible with most mid and full tower cases.

EPS

Similar to ATX but with additional support for powerful systems or servers, usually with 8pin+4pin CPU connectors

Modularity

Full Wired

Modularity

Describes the degree to which power cables are detachable. Modular power supplies allow for the use of only necessary cables, resulting in better aesthetics and airflow.

Full Wired

The cables are not detachable from the power supply.

Certification

80 Plus Standard

Certification

80 Plus Standard

The 80 PLUS Standard is an energy efficiency certification that ensures the power supply operates with at least 80% efficiency at 20%, 50%, and 100% load. This means less power consumption, less heat, and greater reliability.

Fan Dimension

120 mm

Fan Dimension

The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.

Power Protection

Over Power Protection (OPP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), Surges & Inrush Protection (SIP), Under Voltage Protection (UVP)

Power Protection

The various types of protection that the power supply has.

Over Power Protection (OPP)

Protects the power supply if its nominal power is exceeded.

Over Voltage Protection (OVP)

Protects connected devices from excessive voltage.

Short Circuit Protection (SCP)

Protects the power supply from short circuit.

Surges & Inrush Protection (SIP)

Protects the power supply during connection to the socket and from strong network fluctuations.

Under Voltage Protection (UVP)

Protects connected devices from low voltage current.

Color

Black

ATX Version

ATX 3.1

-
