The JBL MA9100HP amplifier delivers 140 W per channel at 8 Ω and supports Dolby Atmos and DTS:X decoding, with configurations of up to 9.1, 7.1.2 or 5.1.4 channels. Its low-noise Class D amplification operates across nine channels, while six HDMI inputs and two HDMI outputs, along with eARC, allow you to connect a TV or projector and other devices.
It supports 8K and 4K video, as well as HDR 10+ and Dolby Vision. For music playback, it features built-in streaming via Apple AirPlay 2, Google Chromecast and Bluetooth AptX Adaptive, while the Moving Magnet phono input lets you connect a turntable. It is Dirac Live Ready for automatic sound correction tailored to your room’s acoustics. The second HDMI output and audio zone let you send content to another room, and IP control is supported for integration with third-party control systems.
- Channels: 9.2
- Power per channel at 8 Ω: 140 W
- Amplification: Low-noise Class D across nine channels
- Channel configurations: Up to 9.1, 7.1.2 or 5.1.4
- Audio decoding: Dolby Atmos, DTS:X
- Video resolution: 8K, 4K
- HDR: HDR 10+, Dolby Vision
- HDMI inputs: 6
- HDMI outputs: 2
- HDMI eARC: Yes
- HDMI 2.1 inputs for 8K/60 Hz and 4K/120 Hz: 3
- HDMI gaming features: VRR, ALLM, QFT, HFR
- Streaming: Apple AirPlay 2, Google Chromecast
- Bluetooth: AptX Adaptive
- Turntable input: Moving Magnet phono
- Room correction: Dirac Live Ready
- Video output and audio zone: For a second room
- Control: Via IP
- Width: 43.2 cm
- Height: 13.5 cm
- Depth: 39.6 cm
- Weight: 8 kg
- Colour: Silver
Technical Specifications
- Channels
- 9.2
- Power (8Ω)
- 140 watt / channel
- 4K
- Yes
- 8K
- Yes
- HDR
- Yes
- Dolby Atmos
- Yes
- DTS:X
- Yes
Connectivity
- HDMI in
- 6
- HDMI out
- 2
- Digital Optical
- Without
- Ethernet
- Yes
- Wi-Fi
- Yes
- Bluetooth
- Yes
- NFC
- No
Features & Functions
- Automatic Calibration
- No
- Multiroom Function
- No
- Streaming
- Chromecast, Airplay 2
- Radio
- No
Dimensions
- Width
- 43.2 cm
- Height
- 13.5 cm
- Length
- 39.6 cm
Main Specifications
- Colour
- Silver
- Weight
- 8 kg
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
