LINEAR FLOOR DRAIN WITH STAINLESS STEEL FRAME SIDE OUTLET D40 850MM MAT GRATE KLASIK/FLOOR

A linear floor drain is essential for absolutely every bathroom. Due to its unique odor-resistant design, low installation height, high flow rate, and a wide range of stainless steel grate widths, it meets the demands of the most discerning customers and is the ideal solution for your bathroom.

The base is made of polypropylene, and the frame and grid are constructed from stainless steel DIN 1.4301, allowing for a load capacity of K3 (up to 300 kg). The minimum installation height is 65 mm, and the drainage is height adjustable. Designed for connection to drainage pipes Ø 40/50 mm.

• Low installation height of 50 mm
• Height adjustment between 65 to 87 mm
• Flow rate of 30-38 l/min according to EN 1253
• Siphon with water level combined with dry flaps
• Loading capacity K3 (300 kg)
• Stainless steel grate 1.5 mm polished/matte
• Size range 350, 450, 550
