GRsistemi Garage Door Motor Set for Counterweight Door up to 250kg Right Direction
Garage Door Motor Set

GRsistemi Garage Door Motor Set for Counterweight Door up to 250kg Right Direction

The GRsistemi SW400-KIT-7 motor kit automates a double-leaf swing gate, with mechanisms for both right- and left-hand installation. It includes two linear electromechanical motors with permanent...

The GRsistemi SW400-KIT-7 motor kit automates a double-leaf swing gate, with mechanisms for both right- and left-hand installation. It includes two linear electromechanical motors with permanent lithium grease lubrication and a non-reversible mechanism. Each motor operates a leaf weighing up to 250 kg and measuring up to 3 m wide, with a maximum opening...

See full description See full description
505 00 €
Delivery by Thu, 12 Nov
38,00 €   shipping cost
Sent from Greece
From NextSystems
Greece
20+ pieces
See Garage Door Mechanisms on the page of NextSystems

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.

Learn more about invoicing
Review the product
Product report

Description

Description

The GRsistemi SW400-KIT-7 motor kit automates a double-leaf swing gate, with mechanisms for both right- and left-hand installation. It includes two linear electromechanical motors with permanent lithium grease lubrication and a non-reversible mechanism. Each motor operates a leaf weighing up to 250 kg and measuring up to 3 m wide, with a maximum opening angle of 120°.

The kit includes a control panel, seven wireless remote controls, a wired safety photocell set and an LED warning light. In the event of a power outage, the mechanism can be disengaged with a special key, allowing the gate to be operated manually.

  • Gate type: Swing, double-leaf
  • Mechanism type: Linear, electromechanical, permanently lubricated with lithium grease, non-reversible
  • Direction: Right- and left-hand
  • Motors: 2 units
  • Maximum leaf weight: 250 kg
  • Maximum leaf width: 3 m
  • Maximum opening angle: 120°
  • Usable piston stroke: 40 cm
  • Opening and closing cycles per hour: Up to 20 at 20°C
  • Motor operating voltage: 230 Vac, single-phase
  • Motor power consumption: 330 W each
  • Control panel: 1 unit, S7-150
  • Remote controls: 7 wireless, Wiz
  • Safety photocells: 1 wired transmitter and receiver set, VG-PC-2
  • Warning light: 1 LED, VG-LED
  • Package contents: Mounting brackets and pins, 2 x 8 μF capacitors, 2 release keys, installation instructions in Greek
  • Automatic closing: Adjustable
  • Electric lock connection: Connection available
  • Warning light connection: 230 Vac or 24 Vdc, intermittent operation
  • Lighting connection: 230 Vac, continuous operation
  • Photocell connection: Indoor and outdoor, activated during closing with the option to reverse the gate to opening
  • Slow stop: Adjustable
  • Motor torque adjustment: Adjustable
  • Protection rating: IP43
  • Housing material: Aluminum
  • Housing color: Black
  • Country of origin: Italy

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Motor type
Counterweight

Motor type

Counterweight
It is flexible and practical in spaces that have enough depth for opening their leaves.
Maximum Weight
250 kg

Maximum Weight

Describes the maximum weight of the garage door that is suitable for the motor.
Maximum Door Length
3 m

Maximum Door Length

Indicates the maximum door length or width that the motor can safely operate.
Built-in Control Panel
No
Wi-Fi
No

Wi-Fi

Allows remote control and monitoring of the motor via a smartphone app, by connecting it to the home Wi-Fi network.

Set Contents

Motor
2 pcs
Control Panel
1 pcs

Control Panel

1

It regulates and manages the operation of the motor, the commands from the remote controls, and the safety accessories.
Remote Control
7 pcs
Security Beacon
1 pcs

Security Beacon

During motor operation, it flashes indicating that the door is moving. It is used as a safety accessory and where there is low visibility when exiting the vehicle.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The GRsistemi SW400-KIT-7 motor kit automates a double-leaf swing gate, with mechanisms for both right- and left-hand installation. It includes two linear electromechanical motors with permanent lithium grease lubrication and a non-reversible mechanism. Each motor operates a leaf weighing up to 250 kg and measuring up to 3 m wide, with a maximum opening angle of 120°.

The kit includes a control panel, seven wireless remote controls, a wired safety photocell set and an LED warning light. In the event of a power outage, the mechanism can be disengaged with a special key, allowing the gate to be operated manually.

  • Gate type: Swing, double-leaf
  • Mechanism type: Linear, electromechanical, permanently lubricated with lithium grease, non-reversible
  • Direction: Right- and left-hand
  • Motors: 2 units
  • Maximum leaf weight: 250 kg
  • Maximum leaf width: 3 m
  • Maximum opening angle: 120°
  • Usable piston stroke: 40 cm
  • Opening and closing cycles per hour: Up to 20 at 20°C
  • Motor operating voltage: 230 Vac, single-phase
  • Motor power consumption: 330 W each
  • Control panel: 1 unit, S7-150
  • Remote controls: 7 wireless, Wiz
  • Safety photocells: 1 wired transmitter and receiver set, VG-PC-2
  • Warning light: 1 LED, VG-LED
  • Package contents: Mounting brackets and pins, 2 x 8 μF capacitors, 2 release keys, installation instructions in Greek
  • Automatic closing: Adjustable
  • Electric lock connection: Connection available
  • Warning light connection: 230 Vac or 24 Vdc, intermittent operation
  • Lighting connection: 230 Vac, continuous operation
  • Photocell connection: Indoor and outdoor, activated during closing with the option to reverse the gate to opening
  • Slow stop: Adjustable
  • Motor torque adjustment: Adjustable
  • Protection rating: IP43
  • Housing material: Aluminum
  • Housing color: Black
  • Country of origin: Italy

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Motor type
Counterweight

Motor type

Counterweight
It is flexible and practical in spaces that have enough depth for opening their leaves.
Maximum Weight
250 kg

Maximum Weight

Describes the maximum weight of the garage door that is suitable for the motor.
Maximum Door Length
3 m

Maximum Door Length

Indicates the maximum door length or width that the motor can safely operate.
Built-in Control Panel
No
Wi-Fi
No

Wi-Fi

Allows remote control and monitoring of the motor via a smartphone app, by connecting it to the home Wi-Fi network.

Set Contents

Motor
2 pcs
Control Panel
1 pcs

Control Panel

1

It regulates and manages the operation of the motor, the commands from the remote controls, and the safety accessories.
Remote Control
7 pcs
Security Beacon
1 pcs

Security Beacon

During motor operation, it flashes indicating that the door is moving. It is used as a safety accessory and where there is low visibility when exiting the vehicle.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
