GRsistemi Garage Door Motor Set for Counterweight Door Up to 250kg Right Direction
Garage Door Motor Set

GRsistemi Garage Door Motor Set for Counterweight Door Up to 250kg Right Direction

The GRsistemi SW400-VG-WIZ-BLUE gate opener kit automates a two-leaf swing garage door and uses right-hand motors. It includes two linear electromechanical operators with permanent grease lubrication,...

The GRsistemi SW400-VG-WIZ-BLUE gate opener kit automates a two-leaf swing garage door and uses right-hand motors. It includes two linear electromechanical operators with permanent grease lubrication, an S7-150 control unit and two WIZ-BLUE remote controls. Each motor drives a gate leaf weighing up to 250 kg and measuring up to 3.5 m wide; an electric lock...

See full description See full description
430 00 €
Delivery by Thu, 12 Nov
38,00 €   shipping cost
Sent from Greece
From NextSystems
Greece
20+ pieces
See Garage Door Mechanisms on the page of NextSystems

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.

Learn more about invoicing
Review the product
Product report

Description

Description

The GRsistemi SW400-VG-WIZ-BLUE gate opener kit automates a two-leaf swing garage door and uses right-hand motors. It includes two linear electromechanical operators with permanent grease lubrication, an S7-150 control unit and two WIZ-BLUE remote controls. Each motor drives a gate leaf weighing up to 250 kg and measuring up to 3.5 m wide; an electric lock is required for leaves wider than 2.5 m.

The control unit supports automatic closing, motor force adjustment, soft stopping and connection of safety photocells, a warning light and an electric lock. In the event of a power failure, the operators can be disengaged with a key to allow the door to be moved manually.

  • Type: Swing garage door motor kit
  • Direction: Right-hand
  • Maximum gate leaf weight: 250 kg
  • Maximum width per gate leaf: 3.5 m
  • Operator type: Linear, electromechanical, non-reversible, with permanent grease lubrication
  • Usable piston stroke: 40 cm
  • Maximum opening angle: 120°
  • Duty cycle: 35% - S3
  • Opening and closing cycles per hour: Up to 20 at 20 °C
  • Operating voltage: 230 Vac, single-phase
  • Motor power: 330 W
  • Maximum force: 2200 N
  • Protection rating: IP43
  • Operating temperature: From -25 °C to 60 °C
  • Number of motors: 2
  • Control unit: 1, model S7-150
  • Remote controls: 2, model WIZ-BLUE
  • Remote control frequency: 433.92 MHz
  • Remote control coding: Rolling Code
  • Remote control buttons: 4
  • Remote control range: Approximately 50 m
  • Maximum number of registered remote controls: 250
  • Safety photocells: AGO-20 wired photocell set with transmitter and receiver
  • Warning light: 1 LED, model VG-LED
  • Housing material: Aluminium
  • Housing colour: Black
  • Control unit functions: Automatic closing, motor force adjustment, soft stopping and LED diagnostics
  • Disengagement: Key-operated
  • Package contents: 2 mounting brackets and pins, 2 8 μF capacitors, 2 release keys and installation instructions in Greek

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Motor type
Counterweight

Motor type

Counterweight
It is flexible and practical in spaces that have enough depth for opening their leaves.
Maximum Weight
250 kg

Maximum Weight

Describes the maximum weight of the garage door that is suitable for the motor.
Maximum Door Length
3.5 m

Maximum Door Length

Indicates the maximum door length or width that the motor can safely operate.
Built-in Control Panel
No
Wi-Fi
No

Wi-Fi

Allows remote control and monitoring of the motor via a smartphone app, by connecting it to the home Wi-Fi network.

Set Contents

Motor
2 pcs
Control Panel
1 pcs

Control Panel

1

It regulates and manages the operation of the motor, the commands from the remote controls, and the safety accessories.
Remote Control
2 pcs
Security Beacon
1 pcs

Security Beacon

During motor operation, it flashes indicating that the door is moving. It is used as a safety accessory and where there is low visibility when exiting the vehicle.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
