Dimensions

Type

MMA

Type

MMA

Creates thick and strong bonds without the need for external gas supply, making it ideal for out-of-lab welding.

Welding Current (max)

160 A

Welding Current (max): 160

Suitable for use in medium-thickness metal constructions and pipelines.

Operation Cycle (max Ampere)

20 %

Operation Cycle (max Ampere)

The Duty Cycle is the portion of a ten-minute period that a welding machine can operate continuously at maximum Amperes before it needs to stop and cool down.

2.

For example, a welding machine with a maximum Amperage of 200 A and a Duty Cycle of 30% can operate continuously at 200 A for 3 minutes before it needs to stop.

Supply Voltage

230 V

Supply Voltage: 230

It is the supply voltage that the machine requires from the electrical grid.

Power

7.1 kVA

Power: 7.1

Affects the power consumption of the machine and determines if it can be supported by the electrical network you are using.

Weight

3900 gr

Additional Features

Inverter

Yes

Inverter

New technology welding. Very good in terms of performance, durability, and weight, but with a high cost of repair in case of damage. They have automation for better and safer work. If connected to a generator, it is recommended to choose one with 8kVA or more.

IGBT

Yes

IGBT

Allows the conversion of direct current (DC) voltage to alternating current (AC) or the output of direct current at a higher or lower intensity.

VRD

No

with Voltage Stabilizer

No

for Generator with AVR

No

Features

Hot Start

Yes

Hot Start

Temporarily increases the current intensity at the moment of welding initiation.

Anti Stick

Yes

Anti Stick

Cuts off the current if the electrode sticks to the metal, to prevent it from burning.

Arc Force

Yes

Arc Force

Helps in the stability of the arc during welding.

2T Operation

No

4T Mode

No

Spot Function

No

Pulsed

No
