Nominal Capacity: 2400 W

Battery Type: 48 V DC

Maximum Battery Voltage: 60 V DC

Input Range: 190 - 260 V AC

Input Frequency: 45 - 60 Hz

Output Range: 230 V AC +/-5%

Output Frequency: 50/60 Hz +/-0.5 Hz

Output Waveform: Pure sine wave

Output Efficiency: >= 85% (DC to AC)

Battery Charging Current: 10 A / 15 A

Battery Capacity: 50-300 Ah (recommended: 100 Ah)

Estimated Charging Time: 4-14 hours (depending on battery capacity)

Switching Time: =

Protections:

• Against overload
• Against short circuit
• Against very high or very low voltage

Permissible Operating Temperature: 0 - 40°C

Permissible Humidity: 10 - 90%
