Features:
- Coaxial two-way ceiling speaker, with 83mm woofer (3.25 in) and 20 mm (0.75 in) neodymium dome tweeter.
- Suitable for indoor use.
- Frequency response, (+/-3 dB), 85 - 19,000 Hz.
- Dispersion, (conical), 135°, (1 - 4 kHz).
- Power in long-term continuous, 30 W.
- Peak power, 120 W.
- Sensitivity (SPL/1W @ 1 m), 83dB.
- Maximum SPL@1m, 98dB, 104dB peak.
- Impedance 8 Ω (transformer bypass).
- Transformer taps: 70V: 3, 6, 12, 25 W, bypass. 100V: 6, 12, 25 W, bypass.
- Metal backcan.
- External dimensions (grille diameter x depth) 255 x 154 mm.
- Backcan dimensions (diameter x depth) 203 x 144 mm.
- Mounting hole size (diameter) 208 mm.
- Magnetically mounted grille with safety cord and paintable option.
- Dispersion alignment system, 127 mm (5 in) diameter.
- Option to rotate or remove the logo.
- Black color.
- Weight 2.68 kg.
- Product Number
- 829708-0220
Technical Specifications
- Power (RMS)
- 25 W
- Driver Configuration
- 2 No of Drivers
- Nominal Impendance
- 8 ohm
- Sensitivity
- 98 dB
Main Specifications
- Placing
- Ceiling
- Quantity
- Piece
- Colour
- White
- Functionality
- Passive
