The Aqara H2 double wall switch controls lighting and connects via Zigbee, Thread or Bluetooth. It supports Google Home and Alexa, and is also compatible with Matter when connected to an Aqara hub. It can be installed with or without a neutral wire.
The switch has LED indicators for operating status and monitors energy consumption. Overheating and overload protection is available when the installation includes a neutral wire.
- Type: Standard
- Number of switches: Double
- Design: Complete
- Function: Lighting
- Colour: White
- Connectivity: Zigbee, Thread, Bluetooth
- Smart home ecosystems: Google Home, Alexa, Matter via Aqara hub
- Illuminated: Yes, with LED indicators
- Wiring: With or without a neutral wire
- Energy consumption monitoring: Yes
- Protection: Overheating and overload protection with a neutral wire
- Operating voltage: 200–240 V AC, 50/60 Hz
- Maximum output current: 8 A per channel for resistive loads
- Minimum load: 5 W
- Power consumption: < 1.3 W
- Dimensions: 86 × 86 × 45 mm
- Operating temperature: 0 °C–40 °C
- Operating humidity: 5%–95% RH
- Ingress protection rating: IP20
Specifications
- Switch Type
- Complete
- Switch Type
- Basic
- Number of Switches
- Two-Way
- Mode
- Lighting
- Colour
- White
Functions
- Aller Retour
- No
- Medium
- No
- Illuminated
- Yes
- Waterproof
- No
- Battery-powered
- No
Smart Attributes
- Smart Ecosystem
- Google Home, Alexa
- Connectivity
- ZigBee
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
