Baofeng BF-17M Wireless Transceiver UHF/VHF 5W with Color Screen In Orange Color
CB & Two-Way Radios

Baofeng BF-17M Wireless Transceiver UHF/VHF 5W with Color Screen In Orange Color

Key features:

  • 1.77” color LCD display
  • Output power (w): 3w-5w
  • 1800mAh battery
  • GPS
  • IP55 waterproof rating
  • Input voltage 7.4 VDC
See full description

  • Type

    UHF/VHF

    UHF (Ultra High Frequency) and VHF (Very High Frequency) transceivers use different frequencies for communication, with UHF offering better coverage in indoor spaces and VHF being ideal for long distances in open areas, such as at sea or in rural areas.
  • See all
Review the product
Product report

Description

Description

  • Standby 45 mA
  • Reception 380 m
  • Transmission ≤1.6A (High power), ≤1.2A (Low power)
  • Operating temperature -10°C to 60°C
  • Antenna resistance 50 ohm
  • Dimensions 135mm*61mm*39mm (without antenna)
  • Weight 260g (with battery)

Transmitter

  • Frequency range (TX) 136-174MHz & 200-260MHz & 400-520MHz
  • RF output power 5 Watt
  • Modulation 16K ΦF3E/11K ΦF3E
  • Spurious Emission -16dBm< 1GHz, -16dBm> 1GHz
  • Frequency Stability ±2.5 ppm
  • Audio Distortion ≤5%
  • FM Hum & Noise 40dB

Receiver

  • Frequency Range
  • VHF2: 136-174 MHz & UHF 400-520 MHz (Scanning Receiver)
  • FM: 65-108 MHz (RX) AM: 108-130 MHz (RX)
  • VHF1: 350-355 MHz (RX)
  • VHF3: 200-260 MHz
  • Sensitivity: 12dB SINAD -120dBM
  • Adjacent Channel Selectivity -60dBm
  • Modulation and Rejection -70dBm
  • Nominal Audio Output Power 0.75Watts 16ohm
  • Nominal Audio Distortion ≤5%

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Type
UHF/VHF

Type

UHF/VHF
UHF (Ultra High Frequency) and VHF (Very High Frequency) transceivers use different frequencies for communication, with UHF offering better coverage in indoor spaces and VHF being ideal for long distances in open areas, such as at sea or in rural areas.
Colour
Orange
Maximum Range
5 km
Channels
999
Pieces
1 pcs
Protection
IP55
Maximum Power
5 W
Display
Coloured
With Earpiece
No
Rechargeable Battery
Yes
Weight
260 gr

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

  • Standby 45 mA
  • Reception 380 m
  • Transmission ≤1.6A (High power), ≤1.2A (Low power)
  • Operating temperature -10°C to 60°C
  • Antenna resistance 50 ohm
  • Dimensions 135mm*61mm*39mm (without antenna)
  • Weight 260g (with battery)

Transmitter

  • Frequency range (TX) 136-174MHz & 200-260MHz & 400-520MHz
  • RF output power 5 Watt
  • Modulation 16K ΦF3E/11K ΦF3E
  • Spurious Emission -16dBm< 1GHz, -16dBm> 1GHz
  • Frequency Stability ±2.5 ppm
  • Audio Distortion ≤5%
  • FM Hum & Noise 40dB

Receiver

  • Frequency Range
  • VHF2: 136-174 MHz & UHF 400-520 MHz (Scanning Receiver)
  • FM: 65-108 MHz (RX) AM: 108-130 MHz (RX)
  • VHF1: 350-355 MHz (RX)
  • VHF3: 200-260 MHz
  • Sensitivity: 12dB SINAD -120dBM
  • Adjacent Channel Selectivity -60dBm
  • Modulation and Rejection -70dBm
  • Nominal Audio Output Power 0.75Watts 16ohm
  • Nominal Audio Distortion ≤5%

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
UHF/VHF

Type

UHF/VHF
UHF (Ultra High Frequency) and VHF (Very High Frequency) transceivers use different frequencies for communication, with UHF offering better coverage in indoor spaces and VHF being ideal for long distances in open areas, such as at sea or in rural areas.
Colour
Orange
Maximum Range
5 km
Channels
999
Pieces
1 pcs
Protection
IP55
Maximum Power
5 W
Display
Coloured
With Earpiece
No
Rechargeable Battery
Yes
Weight
260 gr

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

46,00 €
14,00 €   shipping cost
