Technical Specifications:
- Screen Diagonal: 32”
- Panel Technology: IPS
- Native Resolution: 1,920 x 1,080 (FHD)
- Brightness: 500 nit
- Contrast Ratio: 1,000:1
- Color Gamut: NTSC 72%
- Viewing Angle (Horizontal x Vertical): 178 x 178
- Color Depth: 8bit, 16.7 million colors
- Response Time: 9ms (G to G)
- Surface Treatment (Haze): Haze 25%
- Operating Hours (hours/days): 24/7
- Vertical/Horizontal: Yes/Yes
- Touch Available: Yes
- Touch Object Size: Ø6mm
- Accuracy: 3.5 mm
- Interface: USB 2.0
- Operating System Support: Win 10/11, Android
- Max Touch Points: 10 points
Mechanical Specifications:
- Frame Color: Black
- Frame Width: 11.3 / 11.3 / 11.3 / 13.2 mm
- Weight (head): 5.8 kg
- Packed Weight: 6.9 kg
- Screen Dimensions (W × H × D): 723.0 x 419.4 x 39.1 mm
- Box Dimensions (W × H × D): 812 x 510 x 142 mm
- VESA™ Mounting Hole: 200 x 200
Main Features (hardware):
- Internal Memory: 8GB (System 5GB + Available 2.48GB)
- Temperature Sensor: Yes
- Accelerometer (Gyroscope): Yes
Main Feature (software):
- webOS Version: webOS 6.0
- Built-in CMS: Local content scheduling, team management
- USB Plug & Play: Yes
- Debugging: Yes
- Background Image: Startup logo image, No signal image
- Video Label: Yes
- URL Playback: Yes
- Data Setting: Yes
- SNMP: Yes
Environmental Conditions:
- Operating Temperature: 0 °C to 40 °C
- Operating Humidity: 10% to 80%
Power:
- Power Supply: AC 100-240V~, 50/60Hz
- Power Type: Built-in
- Consumption: 48 W
- Maximum Consumption: 65 W
- Energy Saving: 34 W
- Standby Consumption: 0.5 W
- BTU (British Thermal Unit): 164 BTU/Hr (Typical), 222 BTU/Hr (Maximum)
Certification (Standards):
- Safety: CB / NTRL
- EMC: FCC Class "A" / CE / KC
Software Compatibility:
- SuperSign CMS: Yes
- SuperSign Control+: Yes
- SuperSign Cloud: Yes
- LG ConnectedCare: Yes
- Mobile CMS: Yes
Connectivity:
- Inputs: Digital (HDMI(2), HDCP 1.4), RS232C IN, RJ45(LAN), IR IN, USB2.0 Type A(1)
- Outputs: audio, USB2.0 Type B(1)
- OSD Language: English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Traditional), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Arabic, Turkish, Polish
Basic Accessories:
- Power Cable 1.55 M*1
- USB Cable (Type A-Type B) 1.8 M*1
- User Manual
- QSG
- Remote Control (includes 2 batteries)
- RS232C Gender
- IR Receiver
General Characteristics
- Diagonal
- 32 "
- VESA Mount
- 200 x 200 mm
- 24/7 Operating Hours
- Yes
- Digital Signage
- No
- Features & Functions
- Touch Screen
- Connectivity
- Ethernet, HDMI, RS-232, USB-A
Display Features
- Panel Type
- IPS
- Display Technology
- LCD
- Screen Resolution
- 1920x1080
- Brightness
- 500 nits
Orientation
- Vertical Placement
- No
- Horizontal Placement
- Yes
Energy Label
- Energy Class
- G
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
