OBO Bettermann Inspired T2 Panel Lightning Protection 50kA
Panel Lightning Protection

OBO Bettermann Inspired T2 Panel Lightning Protection 50kA Code: 5094656

Surge Protector, Type 2

Complete unit consisting of an upper part and a base, pre-assembled and ready for connection.

Suitable for TN and TT network systems.

The upper part features a plug and can be...

Surge Protector, Type 2

Complete unit consisting of an upper part and a base, pre-assembled and ready for connection.

Suitable for TN and TT network systems.

The upper part features a plug and can be detached from the base without tools. It includes a thermal and dynamic disconnection unit with visual defect indication.

Features:

  • High current conductivity...
See full description See full description

Maximum discharge current (ka)

  1. 20

    from 96,70 €

  2. 40

    from 52,45 €

  3. 50

    from 94,86 €

Learn more about invoicing
Review the product
Product report

Description

Description

Surge Protector, Type 2

Complete unit consisting of an upper part and a base, pre-assembled and ready for connection.

Suitable for TN and TT network systems.

The upper part features a plug and can be detached from the base without tools. It includes a thermal and dynamic disconnection unit with visual defect indication.

Features:

  • High current conductivity and long service life.
  • Connections with labels.
  • Surge current rating (8/20 µs): 50 kA.
  • Dimension: 280V.
  • Installation type: DIN rail 35 mm.
  • Lightning protection zone: LPZ 1→2.
  • Maximum continuous AC voltage: 280 V.
  • Maximum discharge current (8/20 μs): 40 kA.
  • Nominal AC voltage (50/60 Hz): 230 V.
  • Operating temperature: -40 °C to 80 °C.
  • Protection rating: IP20.
  • SPD to EN 61643-11: Type 2.
  • SPD to IEC 61643-1: Class II.
  • Multi-dimensional version: 3+N/PE.

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
5094656
Type
T2

Type

T2

It has the ability to discharge current from indirect lightning strikes, network overvoltages, and arming/disarming of coupling devices in an installation. It is installed on the main panel of buildings.
Replacement Cartridge
No
Maximum Discharge Current (kA)
50

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

Surge Protector, Type 2

Complete unit consisting of an upper part and a base, pre-assembled and ready for connection.

Suitable for TN and TT network systems.

The upper part features a plug and can be detached from the base without tools. It includes a thermal and dynamic disconnection unit with visual defect indication.

Features:

  • High current conductivity and long service life.
  • Connections with labels.
  • Surge current rating (8/20 µs): 50 kA.
  • Dimension: 280V.
  • Installation type: DIN rail 35 mm.
  • Lightning protection zone: LPZ 1→2.
  • Maximum continuous AC voltage: 280 V.
  • Maximum discharge current (8/20 μs): 40 kA.
  • Nominal AC voltage (50/60 Hz): 230 V.
  • Operating temperature: -40 °C to 80 °C.
  • Protection rating: IP20.
  • SPD to EN 61643-11: Type 2.
  • SPD to IEC 61643-1: Class II.
  • Multi-dimensional version: 3+N/PE.

Manufacturer

Manufacturer Details

Warnings & Safety Information
Product Number
5094656
Type
T2

Type

T2

It has the ability to discharge current from indirect lightning strikes, network overvoltages, and arming/disarming of coupling devices in an installation. It is installed on the main panel of buildings.
Replacement Cartridge
No
Maximum Discharge Current (kA)
50

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
