As a gateway that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, the ER605 allows for remote and centralized management, anytime and anywhere. Standalone management via the user interface or Web application is also available to maximize convenience.
Integrated into Omada SDN: Zero-Touch Provisioning, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for convenience and easy management.
Five Gigabit Ports: High-speed wired connectivity.
Up to 3 Ethernet WAN Ports: 1 gigabit WAN port and 2 gigabit WAN/LAN ports with load balancing increase the utilization rate of multi-line broadband connections.
One USB WAN Port for Mobile Broadband: Mobile broadband connection via 4G/3G modem is supported for WAN backup through the USB port.
Highly Secure VPN: Supports up to 20× LAN-to-LAN IPsec, 16× OpenVPN*, 16× L2TP, and 16× PPTP VPN connections.
Rich Security Features: Advanced firewall policies, DoS protection, IP/MAC/URL filtering, and more security features protect your network and data.
Omada SDN—The Smartest Cloud Solution for Business Networking
As a gateway that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, the ER605 allows for remote and centralized management, anytime and anywhere. Standalone management via the user interface or Web application is also available to maximize convenience.
Up to three Gigabit WAN ports & one USB WAN for Mobile Broadband
Two freely interchangeable ports allow the router to support up to three WAN ports for various Internet access requirements. The multi-WAN load balancing function distributes data streams according to the bandwidth ratio of each WAN port to increase the utilization rate of the multi-line broadband connection. Mobile broadband connection via 4G/3G modem through USB port connection is also supported for WAN backup.
High-Security and High-Performance VPN
The ER605 supports IPSec/PPTP/L2TP VPN through IPSec/SSL protocols. The one-click automatic IPSec VPN significantly simplifies VPN configuration and facilitates network management and deployment. It also secures and encrypts private site-to-site data communications traveling over the Internet. This version improves VPN performance by 4–5 times thanks to the open communication line with Omada's user base.
Abundant security features
Powerful Firewall
Advanced firewall policies protect your network and data.
Convenient VLAN Support
Create virtual network segments for improved security and simplified network management.
DoS Defense
Automatically detects and blocks denial-of-service (DoS) attacks such as TCP/UDP/ICMP floods, Ping of Death, and other related threats.
IP/MAC/URL Filtering
Forcefully prevent viruses and attacks from intruders.
IP-MAC Binding
Reserves static IP assignment for clients to defend against ARP attacks and spoofing.
One-Click ALG Activation
One-click ALG activation for applications like FTP, H323, SIP, IPSec, and PPTP.
Internet Access Management Strategy
Administrators can monitor user behavior on the internet and easily determine employee internet access rights and strategies through IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by logging, verifying, and categorizing user access. Appropriate network resources can also be allocated to specific users or guests.
Easy management with the Omada app
Follow the configuration instructions in the free Omada app to get set up in minutes. Omada allows you to configure settings, monitor network status, and manage clients, all from the comfort of a mobile device.
The package includes
- TL-R605
- Power adapter
- Ethernet cable RJ45
- Quick installation guide
Network Specifications
- Type
- Router
- Maximum LAN Speed
- 1000 Mbps
- Portable Hotspot
- No
- Network Standards
- IEEE 802.3/3u, IEEE 802.3ab
Connectivity
- Wireless network
- No
- Ethernet LAN connections
- 4
- ISDN Connection
- No
- SIM slot
- No
Security
- Firewall
- SPI
- MAC Address Filtering
- Yes
Extras
- Virtual Private Network (VPN)
- Yes
- VoIP
- No
- Mesh
- No
