PF600X 600W Black Computer Power Supply Full Wired 80 Plus Bronze
Power Supplies

PF600X 600W Black Computer Power Supply Full Wired 80 Plus Bronze

The Deepcool PF600X computer power supply delivers 600 W of power and uses the ATX 2.52 form factor. Active cooling is provided by a 120 mm fan, while its features include 80 PLUS Bronze certification...

The Deepcool PF600X computer power supply delivers 600 W of power and uses the ATX 2.52 form factor. Active cooling is provided by a 120 mm fan, while its features include 80 PLUS Bronze certification and active power factor correction (PFC).

  • Power: 600 W
  • Type: ATX
  • Cable type: Fixed
  • Efficiency certification: 80 PLUS Bronze
  • Fans: 1
  • Fan diameter: 120 mm
  • ...
See full description See full description

Top specs

  • Type

    Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

    ATX

    The most common power supply size, compatible with most mid and full tower cases.

  • Certification

    80 Plus Bronze

    Energy saving with efficiency up to 85%. Reliable and efficient operation for your computer's power supply.

  • Fan Dimension

    The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.
  • See all

Learn more about invoicing
Product report

Description

Description

The Deepcool PF600X computer power supply delivers 600 W of power and uses the ATX 2.52 form factor. Active cooling is provided by a 120 mm fan, while its features include 80 PLUS Bronze certification and active power factor correction (PFC).

  • Power: 600 W
  • Type: ATX
  • Cable type: Fixed
  • Efficiency certification: 80 PLUS Bronze
  • Fans: 1
  • Fan diameter: 120 mm
  • Cooling: Active
  • Power factor correction: Active
  • Color: Black
  • ATX version: 2.52
  • Maximum +5 V output current: 16 A
  • Maximum +5 Vsb output current: 3 A
  • Maximum +12 V output current: 50 A
  • Maximum +3.3 V output current: 16 A
  • Maximum -12 V output current: 0.3 A
  • Combined +5 V power: 100 W
  • Combined +12 V power: 600 W
  • Combined +3.3 V power: 100 W
  • Combined +5 Vsb power: 15 W
  • Combined -12 V power: 3.6 W
  • Efficiency: 88%
  • Power hold-up time: 16 ms
  • Power Good signal delay: 100–150 ms
  • Protections: OPP, SCP, UVP, SIP, OVP, OCP, OTP, NLO
  • AC input voltage: 200–240 V
  • AC input frequency: 50/60 Hz
  • Input current: 5 A
  • Operating temperature: 0–40 °C
  • Dimensions: 150 × 86 × 140 mm
  • Fan bearing technology: HYB
  • MTBF: 40,000 h
  • Motherboard power connector: 24-pin ATX
  • Motherboard cable length: 55 cm
  • CPU power connector: 4+4 pin
  • SATA power connectors: 8
  • SATA power cable lengths: 450 mm, 600 mm, 750 mm, and 900 mm
  • PCI Express power connectors: 2 × 6+2 pin
  • Package contents: AC cable
  • Compliance certifications: RCM, CE, KC, CCC
  • Sustainability certifications: Triman, WEEE, China RoHS

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Power
600 W
Size
ATX

Size

Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

ATX
The most common power supply size, compatible with most mid and full tower cases.
Modularity
Full Wired

Modularity

Describes the degree to which power cables are detachable. Modular power supplies allow for the use of only necessary cables, resulting in better aesthetics and airflow.

Full Wired
The cables are not detachable from the power supply.
Certification
80 Plus Bronze

Certification

80 Plus Bronze

Energy saving with efficiency up to 85%. Reliable and efficient operation for your computer's power supply.
Fan Dimension
120 mm

Fan Dimension

The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.
Color
Black

ATX Version

ATX 3.1
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (10)

Reviews

4.4
10
4.4
Review this product
  1. 8
  2. 4 stars
    0
  3. 1
  4. 2 stars
    0
  5. 1
Review this product

What do users say? AI-generated summary

Users generally consider it a good power supply, with its main advantages being smooth performance in gaming PCs and good value for money. It is reported to work without issues with powerful processors and graphics cards. However, one user said it stopped working and would not turn back on.

  • dimitris5952
    5
    dimitris5952

    Verified purchase

    This review is about the power: 700 W

    the power supply is just fine for gaming. with an rtx 5060 and a ryzen 7 7800x3d I haven't had any problems so far

    Translated from Greek ·
    Did you find this review helpful?
  • 5
    Shar_Ringan

    Verified purchase

    This review is about the power: 500 W

    good for its money

    Translated from Greek ·
    Did you find this review helpful?
  • 5
    Rafail_Stamatopoulos

    Verified purchase

    This review is about the power: 700 W

    It has been running on my main PC: r7 5700x + rx 6700xt aorus elite, it has no issues at all

    Translated from Greek ·
    Did you find this review helpful?
  • 1
    0 out of 1 members found this review helpful
    MRwho
    This review is about the power: 700 W

    It shut off and never turned back on. It doesn't turn on by itself either.

    Translated from Greek ·
    Did you find this review helpful?
  • 5
    LANTHANON_ANATHEMA

    Verified purchase

    This review is about the power: 500 W

    Excellent!

    Translated from Greek ·
    Did you find this review helpful?
  • 3
    0 out of 2 members found this review helpful
    Eri_Siempou

    Verified purchase

    This review is about the power: 700 W

    quite good

    Translated from Greek ·
    Did you find this review helpful?
  • 5
    alexgk_7

    Verified purchase

    This review is about the power: 700 W

  • 5
    Gdrake

    Verified purchase

  • 5
    Apkey

    Verified purchase

    This review is about the power: 700 W

  • 5
    gkiouzel.89

    Verified purchase

Description & Specifications

The Deepcool PF600X computer power supply delivers 600 W of power and uses the ATX 2.52 form factor. Active cooling is provided by a 120 mm fan, while its features include 80 PLUS Bronze certification and active power factor correction (PFC).

  • Power: 600 W
  • Type: ATX
  • Cable type: Fixed
  • Efficiency certification: 80 PLUS Bronze
  • Fans: 1
  • Fan diameter: 120 mm
  • Cooling: Active
  • Power factor correction: Active
  • Color: Black
  • ATX version: 2.52
  • Maximum +5 V output current: 16 A
  • Maximum +5 Vsb output current: 3 A
  • Maximum +12 V output current: 50 A
  • Maximum +3.3 V output current: 16 A
  • Maximum -12 V output current: 0.3 A
  • Combined +5 V power: 100 W
  • Combined +12 V power: 600 W
  • Combined +3.3 V power: 100 W
  • Combined +5 Vsb power: 15 W
  • Combined -12 V power: 3.6 W
  • Efficiency: 88%
  • Power hold-up time: 16 ms
  • Power Good signal delay: 100–150 ms
  • Protections: OPP, SCP, UVP, SIP, OVP, OCP, OTP, NLO
  • AC input voltage: 200–240 V
  • AC input frequency: 50/60 Hz
  • Input current: 5 A
  • Operating temperature: 0–40 °C
  • Dimensions: 150 × 86 × 140 mm
  • Fan bearing technology: HYB
  • MTBF: 40,000 h
  • Motherboard power connector: 24-pin ATX
  • Motherboard cable length: 55 cm
  • CPU power connector: 4+4 pin
  • SATA power connectors: 8
  • SATA power cable lengths: 450 mm, 600 mm, 750 mm, and 900 mm
  • PCI Express power connectors: 2 × 6+2 pin
  • Package contents: AC cable
  • Compliance certifications: RCM, CE, KC, CCC
  • Sustainability certifications: Triman, WEEE, China RoHS
