Sonoff ZBMINIL2-E Wall Switch Lighting One-Way with Frame White
Electrical Wall Switches

Sonoff ZBMINIL2-E Wall Switch Lighting One-Way with Frame White

SONOFF ZBMINIL2-E Smart ZigBee Wall Switch

The Orb-ZBW1L is a wall switch from the Fusion series that operates with ZigBee technology and does not require a neutral wire. An ideal choice for older...

SONOFF ZBMINIL2-E Smart ZigBee Wall Switch

The Orb-ZBW1L is a wall switch from the Fusion series that operates with ZigBee technology and does not require a neutral wire. An ideal choice for older installations, it works with popular ZigBee hubs for home lighting automation.

Features:

  • Can be installed in standard boxes: round (60 mm) and square (type 86)
  • No...
See full description See full description

  • Function

    Lighting

    The classic switch for turning the lights on and off in any room.
  • Number of Switches One-Way
  • Smart Ecosystem Alexa, Google Home
  • Connectivity ZigBee
  • See all
Product report

Description

Description

SONOFF ZBMINIL2-E Smart ZigBee Wall Switch

The Orb-ZBW1L is a wall switch from the Fusion series that operates with ZigBee technology and does not require a neutral wire. An ideal choice for older installations, it works with popular ZigBee hubs for home lighting automation.

Features:

  • Can be installed in standard boxes: round (⌀60 mm) and square (type 86)
  • No neutral wire required, ideal for apartments
  • Quick and clean installation without wall chiseling
  • Compatible with ZigBee hubs such as SONOFF ZBBridge-P/U, NSPanel Pro, SmartThings, and Amazon Echo devices
  • Create automations and group control for multiple switches

Technical specifications:

  • Microcontroller (MCU): EFR32MG22
  • Power supply: 100-240V~, 50/60Hz, 6A (maximum resistive load)
  • LED load: up to 150W at 100V / up to 300W at 240V
  • Maximum load: 1440W
  • Minimum load: 3W
  • Wireless connectivity: Zigbee 3.0
  • Weight: 80 g
  • Dimensions: 86 × 86 × 35.8 mm
  • Enclosure material: PC plastic (polycarbonate)
  • Recommended wire diameter: 16AWG to 14AWG (copper, solid or stranded wire only)
  • Application: For indoor use
  • Operating temperature range: From -10°C to 40°C
  • Operating humidity range: 5-95% RH, non-condensing

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Switch Type
Complete

Switch Type

Complete

The mechanism, front panel, and decorative frame of the switch are included.
Number of Switches
One-Way
Mode
Lighting

Mode

Lighting

The classic switch for turning the lights on and off in any room.
Colour
White

Functions

Aller Retour
No

Aller Retour

Allows you to control the same light from two different locations. It is ideal for the beginning and end of a corridor or for the entrance of the room and your bedside table.
Medium
No

Medium

It is used when you want to control the same light from three or more locations (e.g. in large corridors or staircases). It always works together with two Aller-Retour switches at the ends of the installation.
Illuminated
No

Illuminated

Emits light in order to indicate whether the switch is activated or to help locate it in the dark.
Waterproof
No
Battery-powered
No

Battery-powered

They offer complete flexibility in placement. They are a practical choice for making your home smart easily and quickly. They do not require complex installation, as they are usually wireless and can be mounted anywhere with simple adhesive tape.

Smart Attributes

Smart Ecosystem
Alexa, Google Home
Connectivity
ZigBee

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (6)

Reviews

5.0
6
5.0
Review this product
  1. 6
  2. 4 stars
    0
  3. 3 stars
    0
  4. 2 stars
    0
  5. 1 star
    0
Review this product

Reviews by our members

Description & Specifications

SONOFF ZBMINIL2-E Smart ZigBee Wall Switch

The Orb-ZBW1L is a wall switch from the Fusion series that operates with ZigBee technology and does not require a neutral wire. An ideal choice for older installations, it works with popular ZigBee hubs for home lighting automation.

Features:

  • Can be installed in standard boxes: round (⌀60 mm) and square (type 86)
  • No neutral wire required, ideal for apartments
  • Quick and clean installation without wall chiseling
  • Compatible with ZigBee hubs such as SONOFF ZBBridge-P/U, NSPanel Pro, SmartThings, and Amazon Echo devices
  • Create automations and group control for multiple switches

Technical specifications:

  • Microcontroller (MCU): EFR32MG22
  • Power supply: 100-240V~, 50/60Hz, 6A (maximum resistive load)
  • LED load: up to 150W at 100V / up to 300W at 240V
  • Maximum load: 1440W
  • Minimum load: 3W
  • Wireless connectivity: Zigbee 3.0
  • Weight: 80 g
  • Dimensions: 86 × 86 × 35.8 mm
  • Enclosure material: PC plastic (polycarbonate)
  • Recommended wire diameter: 16AWG to 14AWG (copper, solid or stranded wire only)
  • Application: For indoor use
  • Operating temperature range: From -10°C to 40°C
  • Operating humidity range: 5-95% RH, non-condensing

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Switch Type
Complete

Switch Type

Complete

The mechanism, front panel, and decorative frame of the switch are included.
Number of Switches
One-Way
Mode
Lighting

Mode

Lighting

The classic switch for turning the lights on and off in any room.
Colour
White

Functions

Aller Retour
No

Aller Retour

Allows you to control the same light from two different locations. It is ideal for the beginning and end of a corridor or for the entrance of the room and your bedside table.
Medium
No

Medium

It is used when you want to control the same light from three or more locations (e.g. in large corridors or staircases). It always works together with two Aller-Retour switches at the ends of the installation.
Illuminated
No

Illuminated

Emits light in order to indicate whether the switch is activated or to help locate it in the dark.
Waterproof
No
Battery-powered
No

Battery-powered

They offer complete flexibility in placement. They are a practical choice for making your home smart easily and quickly. They do not require complex installation, as they are usually wireless and can be mounted anywhere with simple adhesive tape.

Smart Attributes

Smart Ecosystem
Alexa, Google Home
Connectivity
ZigBee

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
