Hikvision DS-7604NXI-K1 DVR
Surveillance Video Recorders

Hikvision DS-7604NXI-K1 DVR

Key features:

  • 4 IP channels.
  • Incoming bandwidth: 40 Mbps.
See full description

  • Number of Channels

    The maximum number of cameras that can be connected to and managed by the recorder

  • Ports

    HDMI

    The digital output for video and audio. It is the standard way to connect the recorder to a modern TV or monitor (PC) and view your cameras in high resolution.

    USB

    Its main use is to connect a mouse for menu navigation and settings. Additionally, it is used to connect a USB stick (flash drive) in order to export (take a backup of) specific video clips that interest you.
  • See all
Review the product
Product report

Description

Description

The Hikvision DS-7604NXI-K1 is a 4-channel recorder (NVR) designed for use with IP cameras. It is ideal for home or small to medium business CCTV installations.


Performance & Playback

  • Synchronous playback: 4 channels simultaneously. HIKVISION
  • Decoding capability: up to 8-ch@1080p.


Connectivity & Specifications

  • Network: 1× RJ-45 10/100/1000 Mbps Ethernet
  • Ports: HDMI + VGA output, 1× SATA for HDD, USB 2.0/3.0, audio in/out.
  • Protocol compatibility: ONVIF, IP camera support, access via applications/software (e.g. Hik-Connect, iVMS) for PC/Mobile.
  • Power consumption: ≤ 10 W (without HDD)


Capabilities

  • Video input channels: 4 IP channels.
  • Supported resolution: Up to 12 MP for 1 channel · up to 8 MP for 2 channels · 4 MP for 4 channels.
  • Incoming bandwidth: 40 Mbps.
  • Video outputs: HDMI (up to 4K / 3840×2160) and VGA.
  • Video compression: H.265+, H.265, H.264+, H.264.
  • Storage: 1× SATA hard drive — up to 10 TB.

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Number of Channels Outputs
4

Number of Channels Outputs

The maximum number of cameras that can be connected to and managed by the recorder
WiFi
No

WiFi

Specifies whether the device can connect wirelessly to your router (Wi-Fi)
Gigabit Port
No

Gigabit Port

Specifies the speed of the wired network connection (LAN). "Gigabit" (1000 Mbps) is 10 times faster than standard "Fast Ethernet" (100 Mbps). It is essential for multi-channel 4K NVRs to handle the large volume of data from the cameras without delay.
Ports
HDMI, USB

Ports

HDMI
The digital output for video and audio. It is the standard way to connect the recorder to a modern TV or monitor (PC) and view your cameras in high resolution.
USB

Its main use is to connect a mouse for menu navigation and settings. Additionally, it is used to connect a USB stick (flash drive) in order to export (take a backup of) specific video clips that interest you.
ONVIF
No

ONVIF

ONVIF is a protocol that allows cameras and recorders from different manufacturers to communicate with each other.

Smart AI Detection

Human Detection
Yes

Human Detection

The technology recognizes human shapes in real time. Ideal for security, area monitoring, or alarms, reducing false alarms caused by other objects.
Vehicle Detection
Yes

Vehicle Detection

Recognizes and tracks vehicles, distinguishing them from other objects. Useful for parking, traffic management, or road surveillance.

HDD

Includes Hard Drive
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The Hikvision DS-7604NXI-K1 is a 4-channel recorder (NVR) designed for use with IP cameras. It is ideal for home or small to medium business CCTV installations.


Performance & Playback

  • Synchronous playback: 4 channels simultaneously. HIKVISION
  • Decoding capability: up to 8-ch@1080p.


Connectivity & Specifications

  • Network: 1× RJ-45 10/100/1000 Mbps Ethernet
  • Ports: HDMI + VGA output, 1× SATA for HDD, USB 2.0/3.0, audio in/out.
  • Protocol compatibility: ONVIF, IP camera support, access via applications/software (e.g. Hik-Connect, iVMS) for PC/Mobile.
  • Power consumption: ≤ 10 W (without HDD)


Capabilities

  • Video input channels: 4 IP channels.
  • Supported resolution: Up to 12 MP for 1 channel · up to 8 MP for 2 channels · 4 MP for 4 channels.
  • Incoming bandwidth: 40 Mbps.
  • Video outputs: HDMI (up to 4K / 3840×2160) and VGA.
  • Video compression: H.265+, H.265, H.264+, H.264.
  • Storage: 1× SATA hard drive — up to 10 TB.

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Number of Channels Outputs
4

Number of Channels Outputs

The maximum number of cameras that can be connected to and managed by the recorder
WiFi
No

WiFi

Specifies whether the device can connect wirelessly to your router (Wi-Fi)
Gigabit Port
No

Gigabit Port

Specifies the speed of the wired network connection (LAN). "Gigabit" (1000 Mbps) is 10 times faster than standard "Fast Ethernet" (100 Mbps). It is essential for multi-channel 4K NVRs to handle the large volume of data from the cameras without delay.
Ports
HDMI, USB

Ports

HDMI
The digital output for video and audio. It is the standard way to connect the recorder to a modern TV or monitor (PC) and view your cameras in high resolution.
USB

Its main use is to connect a mouse for menu navigation and settings. Additionally, it is used to connect a USB stick (flash drive) in order to export (take a backup of) specific video clips that interest you.
ONVIF
No

ONVIF

ONVIF is a protocol that allows cameras and recorders from different manufacturers to communicate with each other.

Smart AI Detection

Human Detection
Yes

Human Detection

The technology recognizes human shapes in real time. Ideal for security, area monitoring, or alarms, reducing false alarms caused by other objects.
Vehicle Detection
Yes

Vehicle Detection

Recognizes and tracks vehicles, distinguishing them from other objects. Useful for parking, traffic management, or road surveillance.

HDD

Includes Hard Drive
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
