On-Off switch Limit 1pcs
On-Off switches

On-Off switch Limit 1pcs Code: 03.015.0095

The limit switch is metal, with a push button and a die-cast zinc body. It has galvanically isolated contacts and M20, PG13.5, and 1/2” NP cable entries.

It has 1NO+1NC contacts and an IP67 protection...

The limit switch is metal, with a push button and a die-cast zinc body. It has galvanically isolated contacts and M20, PG13.5, and 1/2” NP cable entries.

It has 1NO+1NC contacts and an IP67 protection rating.

  • Quantity: 2
  • Type: Limit switch
  • Rated current: 10 A
  • Rated voltage: 600 VAC
  • Insulation resistance: >100 MΩ at 500 VDC
  • Dielectric strength: 1000 VAC for...
See full description See full description
62 80 €
Delivery Wed, 11 Nov - Tue, 17 Nov
14,00 €   shipping cost
Sent from Greece
From Galazoula 5.0 (5)
5.0 (5 reviews)
Greece
1 piece
See Microelectronic Components on the page of Galazoula

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.

Learn more about invoicing
Review the product
Product report

Description

Description

The limit switch is metal, with a push button and a die-cast zinc body. It has galvanically isolated contacts and M20, PG13.5, and 1/2” NP cable entries.

It has 1NO+1NC contacts and an IP67 protection rating.

  • Quantity: 2
  • Type: Limit switch
  • Rated current: 10 A
  • Rated voltage: 600 VAC
  • Insulation resistance: >100 MΩ at 500 VDC
  • Dielectric strength: 1000 VAC for 60 s between live parts and 2000 VAC for 60 s between non-live parts
  • Mechanical life: 10⁷ operations
  • Electrical life: 5×10⁵ operations
  • Contacts: 1NO+1NC
  • Protection rating: IP67
  • Standards: EN 60947-5-1, EN 50047
  • Body material: Die-cast zinc
  • Cable entries: M20, PG13.5, and 1/2” NP

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
03.015.0095
Type
Limit
Colour
-
Features
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The limit switch is metal, with a push button and a die-cast zinc body. It has galvanically isolated contacts and M20, PG13.5, and 1/2” NP cable entries.

It has 1NO+1NC contacts and an IP67 protection rating.

  • Quantity: 2
  • Type: Limit switch
  • Rated current: 10 A
  • Rated voltage: 600 VAC
  • Insulation resistance: >100 MΩ at 500 VDC
  • Dielectric strength: 1000 VAC for 60 s between live parts and 2000 VAC for 60 s between non-live parts
  • Mechanical life: 10⁷ operations
  • Electrical life: 5×10⁵ operations
  • Contacts: 1NO+1NC
  • Protection rating: IP67
  • Standards: EN 60947-5-1, EN 50047
  • Body material: Die-cast zinc
  • Cable entries: M20, PG13.5, and 1/2” NP

Manufacturer

Manufacturer Details

Warnings & Safety Information
Product Number
03.015.0095
Type
Limit
Colour
-
Features
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
