The Wilo Yonos PICO 25/1-8 circulator is designed for hot-water heating systems, air-conditioning applications and industrial installations. It features a wet rotor, threaded connection, EC motor resistant to blocking current, and integrated electronic power control.
The LED display allows the setpoint to be adjusted in 0.1 m increments and shows current power consumption. Electrical connection is tool-free using the Wilo quick connector, while the venting function makes it easy to bleed the pump. It is easy to set up when replacing a conventional circulator with selectable speeds, and the high starting torque helps ensure reliable start-up.
- Type: Electronic circulator
- Application: Heating and air conditioning
- Connection: Threaded
- Motor: EC, resistant to blocking current
- Power control: Integrated electronic control
- Display: LED
- Setpoint adjustment increment: 0.1 m
- Display indication: Current power consumption
- Function: Pump venting
- Electrical connection: Tool-free, with Wilo quick connector
- Starting torque: High
- Length: 168 mm
- Width: 180 mm
- Height: 81 mm
- Weight: 2.15 kg
- Product Number
- 4164019
Product Details
- Electronic
- Yes
- Application
- Heating, Air Conditioning
- Maximum Pressure Head (m)
- -
Dimensions
- Connection Diameter
- -
- Length
- -
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
