The Wilo Yonos PICO 30/1-6 electronic circulator is designed for hot-water heating systems and air-conditioning applications. It features a wet rotor, threaded connection, EC motor resistant to blocking current, and integrated electronic power control.

The LED display allows the setpoint to be adjusted in 0.1 m increments and shows current power consumption. The pump can be connected electrically without tools using the Wilo quick connector and includes a venting function. Preset speeds make adjustment easier when replacing a conventional circulator, while the high starting torque supports reliable startup.

• Manufacturer: Wilo
• Type: Wet-rotor circulator
• Connection: Threaded
• Motor: EC, resistant to blocking current
• Power control: Integrated electronic control
• Applications: Hot-water heating, air conditioning, industrial systems with circulators
• Display: LED
• Setpoint adjustment increment: 0.1 m
• Power consumption display: Current
• Electrical connection: Tool-free, via Wilo quick connector
• Venting function: Pump
• Speed adjustment: With preset speeds
• Starting torque: Very high
• Weight: 2.1 kg
• Length: 160 mm
• Width: 180 mm
• Height: 81 mm
