The Sonoff MINI-DIM-E dimmer switch smoothly adjusts brightness and supports lighting control via Wi-Fi and Matter. It lets you create scenes and schedules, use voice control, and monitor the power consumption of connected lighting. Automatic calibration adapts operation to the connected load.
It supports dimmable LED bulbs up to 200 VA, traditional and halogen bulbs up to 400 W, and dimmable electronic transformers up to 200 W. It is not intended for fluorescent bulbs, LED strips, or inductive loads such as fans. It features overheat and surge protection, and a flame-retardant enclosure.
- Function: Push-button dimmer
- Lighting compatibility: Dimmable LED bulbs, traditional and halogen bulbs, dimmable electronic transformers
- Maximum power: 400 W
- Supply voltage: 220–240 V ~ 50 Hz
- Connectivity: Wi-Fi IEEE 802.11b/g/n 2.4 GHz
- Smart ecosystems: Matter, Google Home, Amazon Alexa, Apple Home, SmartThings, Home Assistant
- Control: Voice, app, schedules, and scenes
- Metering: Power consumption of connected lighting
- Protection: Overheat and surge protection
- Enclosure material: Flame-retardant PC
- Operating temperature: -10 °C to 40 °C
- Dimensions: 86 × 86 mm
- Installation: In type 86 boxes and 60 mm European round boxes
- Certifications: CE, RoHS
- Package contents: Switch, 4 screws, user manual
Dimensions
- Compatibility
- LED
- Type
- Complete
- Mode
- Button
- Power
- 400 W
- Colour
- White
- Power Supply
- 230V
Additional Features
- Illuminated
- No
- Aller Retour
- No
Professional Control
- DMX512
- No
- DALI
- No
Smart Attributes
- Smart Ecosystem
- Google Home, Alexa, Matter
- Connectivity
- Wi-Fi, ZigBee
