The Teltonika TSF000000000 switch combines Gigabit Ethernet ports with SFP ports for wired connectivity and network expansion via fiber optics. It supports PoE+ for data transfer and powering devices, with a total power budget of 120 W. Its low-profile design allows installation in space-constrained areas.

It accepts a 7–57 VDC power supply, while the PoE-Out ports operate with a 44–57 VDC input. It supports jumbo frames and operates in temperatures ranging from -40 °C to 75 °C.

• Type: Layer 2 managed switch
• Ethernet ports: 5 Gigabit Ethernet, 1 Gbps
• SFP ports: 5
• PoE+ ports: 4, with a power budget of 120 W
• PoE standard: IEEE 802.3at
• Mounting: Rack or DIN rail
• Power supply: External, 7–57 VDC
• PoE-Out input voltage: 44–57 VDC
• Power consumption without load: 1 W
• Maximum power consumption without PoE: 1.5 W
• Throughput: 10 Gb/s
• Packet buffer: 128 KB
• MAC address table: 2000 entries
• Jumbo frames: Up to 9,216 KB
• Supported standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3az, IEEE 802.3p, IEEE 802.3Q, IEEE 802.3af, IEEE 802.3at
• Protection rating: IP30
• Operating temperature: -40 °C to 75 °C
• Operating humidity: 5% to 95%, non-condensing
• Dimensions: 113 × 28 × 50 mm
• Weight: 142 g
• Certifications: CE, UKC, RCM, CB, FCC, IC, WEEE
• Package contents: Switch, 3-pin power connector, QSG quick start guide
