The Rode RodeCaster Video analog console combines a 16-channel audio mixer with video production features for livestreaming and studio productions. It supports switching between up to 4 video sources and 5 customizable scenes, while automatic switching can be based on the active audio source.

The 3 HDMI inputs support Full HD 1080p and frame rate conversion, while the configurable HDMI output can display program, preview, or multiview. For audio, the 2 combo XLR/TRS inputs with Revolution Preamps work with per-channel APHEX processing, which includes an equalizer, compressor, noise gate, de-esser, high-pass filter, Aural Exciter, and Big Bottom. NDI over Ethernet, direct RTMP streaming, and Program and ISO recording to external USB storage are also supported.

• Type: Analog
• Channels: 16
• Audio sources: Up to 16 total, with 9 stereo channels simultaneously
• XLR/TRS inputs: 2 Neutrik combo inputs
• Preamps: Revolution Preamps
• Microphone frequency response: 20 Hz–20 kHz
• Preamp gain range: 0–76 dB
• Audio processing: Per-channel APHEX, with EQ, compressor, noise gate, de-esser, high-pass filter, Aural Exciter, and Big Bottom
• Headphone outputs: 2 × 6.35 mm
• HDMI inputs: 3 × Type-A (1.4b)
• HDMI output: 1 configurable
• Video inputs: 3 HDMI and 1 USB UVC
• Video resolution: Up to 1920 × 1080
• Video switching: Up to 4 sources and 5 customizable scenes
• Transition effects: Up to 9 layers, keyers, transitions, SMPTE wipes, dip, and fade
• Display: Multiview with detailed information
• Networking: Ethernet LAN, NDI over Ethernet, and support for up to 4 NDI cameras
• USB connection: 2 USB-C ports for audio/video devices and computers
• USB audio interface: 2 USB-C audio interfaces for simultaneous use with 2 computers
• Streaming: RTMP
• Recording: Program, ISO, and multitrack audio to external USB storage
• Sample rate and bit depth: 48 kHz / 32-bit for streaming and 48 kHz / 24-bit for recording
• Built-in storage: 24 GB for media files
• Compatibility: macOS and Windows
• Power supply: USB-C PD, 45 W
• Weight: 705 g
• Dimensions: 239 × 125 × 45.5 mm
• Color: Black
• Package contents: Power adapter and SuperSpeed USB-C cable
