Access Control for Access with Card
Access Controls

Access Control for Access with Card

The Satel CR-MF3 card reader operates as an access control terminal for MIFARE cards. In INTEGRA systems, it enables arming and disarming the alarm system and cancelling alarms, while in ACCO and ACCO...

The Satel CR-MF3 card reader operates as an access control terminal for MIFARE cards. In INTEGRA systems, it enables arming and disarming the alarm system and cancelling alarms, while in ACCO and ACCO NET systems, it controls passage opening and locking.

In standalone mode, it supports up to 128 cards. It features tamper protection against opening the...

See Description & Specifications See Description & Specifications
231 90 €
Delivery Wed, 18 Nov - Tue, 24 Nov
14,00 €   shipping cost
Sent from Greece
From Getters 4.6 (114)
4.6 (114 reviews)
Greece
4 pieces
See Access Control Systems on the page of Getters

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.

Learn more about invoicing
Review the product
Product report

Description & Specifications

The Satel CR-MF3 card reader operates as an access control terminal for MIFARE cards. In INTEGRA systems, it enables arming and disarming the alarm system and cancelling alarms, while in ACCO and ACCO NET systems, it controls passage opening and locking.

In standalone mode, it supports up to 128 cards. It features tamper protection against opening the enclosure and removing the device from the wall, three LED indicators, and a built-in sounder with adjustable volume. The relay output can control an electric door strike, magnetic lock, or other passage activation device.

  • Function: Card reading
  • Card technologies: MIFARE Ultralight (CSN/SSN), MIFARE Classic (CSN/SSN/MSN), MIFARE DESFire EV1/EV2/EV3 (CSN/MSN)
  • Operating frequency: 13.553–13.567 MHz
  • Encrypted card reading range: Up to 45 mm
  • Interface: OSDP version 2.2 (RS-485), EM-Marin, Wiegand
  • Standalone mode: Up to 128 proximity cards
  • Relay output: 1 A / 30 V DC (resistive load)
  • Inputs: Door status monitoring, exit button
  • Visual indication: 3 LEDs
  • Audible indication: Built-in sounder with adjustable volume
  • Tamper protection: Protection against opening the enclosure and removing the device from the wall
  • Power supply: 12 V DC (±15%)
  • Standby current consumption: 66 mA
  • Maximum current consumption: 110 mA
  • Operating temperature: -25 °C to +55 °C
  • Maximum humidity: 93±3%
  • Dimensions: 47 x 158 x 30 mm
  • Weight: 118 g
  • Installation: Indoor or outdoor
  • Programming: Using the CR Soft program or the MC-SRV-8 service card

Manufacturer

Manufacturer Details

Warnings & Safety Information
Input Type
Card
Attendance Time Clock
No
Waterproof
No
Bluetooth
-
