Category: Thermal Cameras

Technical Specifications

• Bluetooth: Yes
• Maximum memory card size: 64 GB
• Bluetooth version: 5.0
• Wi-Fi: Yes

Design

• Product color: Black
• Display diagonal: 4.3"
• Country of origin: China
• Housing material: Metal
• Touchscreen: Yes
• Built-in display: Yes
• IP protection class: IP54
• Display type: LCD
• Drop resistance: 200 cm

Weight and Dimensions

• Product weight: 1.2 kg
• Product width: 292 mm
• Product depth: 125 mm
• Product height: 125 mm

Performance

• Maximum resolution: 480 x 360 px
• Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays
• Horizontal field of view: 25°
• Infrared spectrum: 7.5 - 14 µm
• Temperature measurement range: -40 - 650 °C
• Thermal refresh rate: 30 Hz
• Vertical field of view: 19°
• Thermal sensitivity (NETD): 30 mK
• Internal memory: 64 GB
• Accuracy: 2 °C
• Built-in laser: Yes

Packaging Data

• Package type: Box

Package Contents

• Included strap: Yes
• Battery charger: Yes
• Cables: USB Type-C to USB Type-C
• Number of batteries included: 2 pcs.
• User manual: Yes

Ports and Interfaces

• USB port: Yes

Battery

• Battery life: 4 hours
• Battery type: Lithium-Ion (Li-Ion)

Lens System

• Sensor resolution (thermal module): 800 x 480 px
• Minimum focal length: 0.15 m
• Focus modes: Auto focus, Continuous auto focus, Manual focus, Touch focus

Optical Module

• Built-in camera: Yes
• Horizontal field of view (optical module): 25°
• Vertical field of view (optical module): 19°
