Category: Thermal Cameras

Technical Details

• Warranty: 2 years
• Bluetooth: Yes (Version 5.0)
• Maximum memory card size: 256 GB
• Wi-Fi: Yes

Design

• Touchscreen: Yes
• IP protection class: IP54
• Product color: Black
• Country of origin: China
• Resolution: 800 x 480 px
• Display diagonal: 4.3"
• Display type: LCD
• Housing material: Metal
• Built-in display: Yes
• Drop resistance: 200 cm

Weight and Dimensions

• Product weight: 1.2 kg
• Product width: 292 mm
• Product depth: 125 mm
• Product height: 125 mm

Performance

• Sensor type (thermal model): Vanadium Oxide Uncooled Focal Plane Arrays
• Vertical field of view: 19°
• Temperature measurement range: -40 - 650 °C
• Built-in memory: 16 GB
• Thermal refresh rate: 30 Hz
• Infrared spectral range: 7.6 - 14 µm
• Horizontal field of view: 25°
• Built-in eyepiece: Yes
• Thermal sensitivity (NETD): 35 mK
• Built-in laser pointer: Yes
• Image frequency: 9 Hz
• Accuracy: 2 °C

Packaging Data

• Packaging type: Box

Package Contents

• Cables
• USB Type-A to USB Type-C
• USB Type-C to USB Type-C

• Wrist strap: Yes
• Battery charger: Yes
• User manual: Yes

Ports and Interfaces

• USB port: Yes
• Supported USB type: USB Type-C

Battery

• Battery life: 5 h

Lens system

• Sensor resolution (thermal model): 256 x 192 px
• Focus modes: Auto focus, Continuous auto focus, Manual focus, Touch focus

Optical model

• Built-in camera: Yes
