Carpoint Electric Vehicle Charging Cable Type2>2 16a 3ph 10 Meter 0290016
Electric Car Charging Station Cables

Carpoint Electric Vehicle Charging Cable Type2>2 16a 3ph 10 Meter 0290016

3-phase Carpoint charging cable for all electric vehicles with Type 2 connection. The cable has a capacity of 16 Amp and charges safely via 3 phases.

  • Charger side plug: male Type 2 (IEC 62196-2) with...

3-phase Carpoint charging cable for all electric vehicles with Type 2 connection. The cable has a capacity of 16 Amp and charges safely via 3 phases.

  • Charger side plug: male Type 2 (IEC 62196-2) with protective cap.
  • Car charging side plug: female Type 2 (IEC 62196-2) with protective cap.
  • Length: 10 meters.
  • Rating: IP55 for outdoor use in all weather...
See full description See full description
199 00 €

-5% for 3+ products

Delivery by Thu, 13 Aug
14,00 €   shipping cost
Sent from Greece
Add at least 3 of the same or different products from the offer and get -5% on every product!

Offer's products

All products in the offer
From Overneed 5.0 (5)
5.0 (5 reviews)
Greece
1 piece
See Car Electronics on the page of Overneed

Learn more about invoicing
Review the product
Product report

Description

Description

3-phase Carpoint charging cable for all electric vehicles with Type 2 connection. The cable has a capacity of 16 Amp and charges safely via 3 phases.

  • Charger side plug: male Type 2 (IEC 62196-2) with protective cap.
  • Car charging side plug: female Type 2 (IEC 62196-2) with protective cap.
  • Length: 10 meters.
  • Rating: IP55 for outdoor use in all weather conditions.
  • Specifications:
    • 16A capacity.
    • Voltage 380-450VAC ± 10%.
    • Insulation resistance >1000MOhm.
    • Withstand voltage 2000V.
    • Contact resistance 50,000 times.
    • Vibration resistance according to JDQ53.3 requirements.
    • Cable type 5 2.5mm² + 2 0.5mm².
    • Operating temperature -40°C ~ 50°C.

It is essential to ensure that the maximum current and phases of the cable are compatible with the requirements of the charger and the car.

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Phase Capacity
Three-phase
Cable Length
10 m
Connection Type
Type 2 - Type 2

Connection Type

  • Type 2: Compatible with all new electric vehicles available in the EU. Maximum charging power of 22kW (43kW at fast charging stations).
  • Type 1: Single-phase plug with a charging power of up to 7.4kW mainly for countries outside the EU.
  • Schuko: The classic plug for household sockets with a maximum charging power of up to 3.7kW.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

3-phase Carpoint charging cable for all electric vehicles with Type 2 connection. The cable has a capacity of 16 Amp and charges safely via 3 phases.

  • Charger side plug: male Type 2 (IEC 62196-2) with protective cap.
  • Car charging side plug: female Type 2 (IEC 62196-2) with protective cap.
  • Length: 10 meters.
  • Rating: IP55 for outdoor use in all weather conditions.
  • Specifications:
    • 16A capacity.
    • Voltage 380-450VAC ± 10%.
    • Insulation resistance >1000MOhm.
    • Withstand voltage 2000V.
    • Contact resistance 50,000 times.
    • Vibration resistance according to JDQ53.3 requirements.
    • Cable type 5 2.5mm² + 2 0.5mm².
    • Operating temperature -40°C ~ 50°C.

It is essential to ensure that the maximum current and phases of the cable are compatible with the requirements of the charger and the car.

Manufacturer

Manufacturer Details

Warnings & Safety Information
Phase Capacity
Three-phase
Cable Length
10 m
Connection Type
Type 2 - Type 2

Connection Type

  • Type 2: Compatible with all new electric vehicles available in the EU. Maximum charging power of 22kW (43kW at fast charging stations).
  • Type 1: Single-phase plug with a charging power of up to 7.4kW mainly for countries outside the EU.
  • Schuko: The classic plug for household sockets with a maximum charging power of up to 3.7kW.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
