Perfexim Electronic Heating Circulator Pump
Circulator Pumps

Perfexim Electronic Heating Circulator Pump

ePCO 32/80Z Circulation Pump for clean water, suitable for central heating installations, industrial thermal systems, and ventilation systems. It can also be used for non-corrosive, low-viscosity...

ePCO 32/80Z Circulation Pump for clean water, suitable for central heating installations, industrial thermal systems, and ventilation systems. It can also be used for non-corrosive, low-viscosity liquids.

  • Touch screen
  • Short circuit protection
  • Airing cap

Technical specifications:

  • Power supply voltage: 230-240 V
  • Flow rate: up to 4.4 m³/h
  • Maximum head: up to...
See full description See full description

Learn more about invoicing
Review the product
Product report

Description

Description

ePCO 32/80Z Circulation Pump for clean water, suitable for central heating installations, industrial thermal systems, and ventilation systems. It can also be used for non-corrosive, low-viscosity liquids.

  • Touch screen
  • Short circuit protection
  • Airing cap

Technical specifications:

  • Power supply voltage: 230-240 V
  • Flow rate: up to 4.4 m³/h
  • Maximum head: up to 8 m
  • Operating pressure: 1.0 MPa
  • Medium temperature: +2 to +110°C
  • Connection diameters: 1/2', 3/4', 1', or 1 1/4'
  • EEI: ≤ 0.20
  • P1 [W]: Min. 7, Max. 60
  • I [A]: Min. 0.05, Max. 0.28
  • Insulation class: H
  • Protection degree: IP44
  • Type: without strainer
  • Body: cast iron
  • Rotor: composite material
  • Motor: modern with permanent magnet
  • Axis and bearings: ceramic
  • Stator: chrome-nickel steel
  • Motor casing: aluminum

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Details

Electronic
Yes

Electronic

Latest technology browsers. They provide high energy efficiency and consume up to 80% less electricity.
Application
Heating

Application

Heating
It concerns installations of closed circuit hot and cold water.
Maximum Pressure Head (m)
8 m

Maximum Pressure Head (m)

A professional engineer is required for the calculation. It is the sum of flow resistances and does not concern the static height of the installation.

Dimensions

Connection Diameter
-
Length
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

ePCO 32/80Z Circulation Pump for clean water, suitable for central heating installations, industrial thermal systems, and ventilation systems. It can also be used for non-corrosive, low-viscosity liquids.

  • Touch screen
  • Short circuit protection
  • Airing cap

Technical specifications:

  • Power supply voltage: 230-240 V
  • Flow rate: up to 4.4 m³/h
  • Maximum head: up to 8 m
  • Operating pressure: 1.0 MPa
  • Medium temperature: +2 to +110°C
  • Connection diameters: 1/2', 3/4', 1', or 1 1/4'
  • EEI: ≤ 0.20
  • P1 [W]: Min. 7, Max. 60
  • I [A]: Min. 0.05, Max. 0.28
  • Insulation class: H
  • Protection degree: IP44
  • Type: without strainer
  • Body: cast iron
  • Rotor: composite material
  • Motor: modern with permanent magnet
  • Axis and bearings: ceramic
  • Stator: chrome-nickel steel
  • Motor casing: aluminum

Manufacturer

Manufacturer Details

Warnings & Safety Information

Product Details

Electronic
Yes

Electronic

Latest technology browsers. They provide high energy efficiency and consume up to 80% less electricity.
Application
Heating

Application

Heating
It concerns installations of closed circuit hot and cold water.
Maximum Pressure Head (m)
8 m

Maximum Pressure Head (m)

A professional engineer is required for the calculation. It is the sum of flow resistances and does not concern the static height of the installation.

Dimensions

Connection Diameter
-
Length
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
