Pulse power supply for DIN rail with adjustable voltage 12-15V, suitable for video intercom systems, including sets with two monitors of the 5tech brand. It features the following protections:
- Overload protection
- Short circuit protection
- Overvoltage protection
- Thermal protection
Additionally, it has an optical operation indicator and support for DIN rail TS-35/7.5 or 15.
Brand: POS
Rated voltage: 15V
Rated current: 4A
Rated power: 60W
Current range: 0 ÷ 4A
Voltage adjustment range: 12 ÷ 15V
Tolerance: ± 2%
Input voltage range: 180 ÷ 264 VAC
Input frequency range: 47 ÷ 63Hz
Efficiency (typical): 89%
AC current (typical): 0.45A/230VAC
Starting current (typical): 29.5A / 230VAC
Dimensions: 62.5 x 93 x 56 mm
Weight: 0.2 kg
Operating temperature: -20°C ÷ +50°C
Operating humidity: 20 ÷ 98%
Certificate: CE
