Finder Four Pole Rail Switch 24V 25A
Electrical Panel Push Buttons Switches

Finder Four Pole Rail Switch 24V 25A

The Finder 22.34.0.024.4320 modular switch is designed for mounting on a 35 mm DIN rail and features four normally open contacts. It is powered by AC/DC and has a mechanical operation indicator and an...

The Finder 22.34.0.024.4320 modular switch is designed for mounting on a 35 mm DIN rail and features four normally open contacts. It is powered by AC/DC and has a mechanical operation indicator and an LED. The coil and contacts can operate continuously, with safe separation and reinforced insulation between them.

The contacts have a double break and a gap of...

See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

The Finder 22.34.0.024.4320 modular switch is designed for mounting on a 35 mm DIN rail and features four normally open contacts. It is powered by AC/DC and has a mechanical operation indicator and an LED. The coil and contacts can operate continuously, with safe separation and reinforced insulation between them.

The contacts have a double break and a gap of at least 3 mm. The contact materials are AgNi and AgSnO2.

  • Number of poles: 4
  • Rated voltage: 24 V
  • Rated current: 25 A
  • Power supply: AC/DC
  • Contacts: 4 normally open
  • Contact gap: ≥ 3 mm
  • Insulation: Reinforced
  • Operation indicator: Mechanical and LED
  • Selector: AUTO-ON-OFF, optional
  • Contact materials: AgNi and AgSnO2
  • Width: 35 mm
  • Length: 9 mm
  • Degree of protection: IP20
  • Mounting: 35 mm DIN rail (PN-EN 60715)
  • Standard: PN-EN 61095 2009
  • Railway applications: Materials compliant with PN-EN 45545-2 + A1 2016

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Number of Poles
4
Nominal Voltage
24 V
Rated Voltage
25 A

Features & Functions

WiFi
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
