BCS BCS-L-NVR6404-A-8K-Ai2 NVR Recorder 64 Channels with 8K Resolution
Surveillance Video Recorders

BCS BCS-L-NVR6404-A-8K-Ai2 NVR Recorder 64 Channels with 8K Resolution

The BCS-L-NVR6404-A-8K-Ai2 is an IP recorder for professional surveillance systems, supporting up to 64 IP cameras and a stated configuration of 32 channels. It supports storage of up to 20 TB across...

The BCS-L-NVR6404-A-8K-Ai2 is an IP recorder for professional surveillance systems, supporting up to 64 IP cameras and a stated configuration of 32 channels. It supports storage of up to 20 TB across 4 SATA drives, as well as archiving to USB FLASH or USB HDD.

It offers the following recording capabilities:

  • Continuous, manual, alarm, motion detection,...
See full description See full description

Top specs

  • Type

    NVR

    Recorder that uses IP cameras and network connection for video recording and management.

  • Number of Channels

    The maximum number of cameras that can be connected to and managed by the recorder
  • Resolution 8K

  • Incoming Bandwidth

    This is the actual processing power of the recorder. It determines how much "load" (data) it can handle simultaneously from all cameras. A high number is necessary for many channels at high 4K resolution.


    • Example 1: You have 4 cameras of 5MP (each requiring ~8 Mbps). A total of ~32 Mbps is required. An NVR with 80 Mbps Incoming Bandwidth is more than enough.
    • Example 2: You have 16 cameras of 4K (each requiring ~12 Mbps). A total of ~192 Mbps is required. An NVR with 160 Mbps is not enough and will "lose" cameras or reduce their quality. Here, you need an NVR with at least 256 Mbps.

    448

  • HDD Slots

    The number of internal hard drives (SATA) that can be installed simultaneously in the recorder.

  • Maximum Capacity per Disk

    The maximum size (in TB - Terabytes) of the hard drive that the device "recognizes" and supports in each slot.

  • ONVIF

    ONVIF is a protocol that allows cameras and recorders from different manufacturers to communicate with each other.

  • Ports

    HDMI

    The digital output for video and audio. It is the standard way to connect the recorder to a modern TV or monitor (PC) and view your cameras in high resolution.

    USB

    Its main use is to connect a mouse for menu navigation and settings. Additionally, it is used to connect a USB stick (flash drive) in order to export (take a backup of) specific video clips that interest you.

    VGA

    An analog video output. Used to connect the recorder to older computer monitors.

    e-Sata

    A specialized, high-speed port that allows the connection of an external hard drive. It is mainly used in professional setups to expand the total storage (recording) capacity.

    Alarm Output

    Physical ports (terminals) that allow the recorder to give a "command" to external devices. For example, "As soon as I detect a person, activate an external siren or turn on the lights."

    Alarm Input

    Physical ports (terminals) that allow external sensors (e.g., door magnetic contact, radar) to send a "command" to the recorder (e.g., "The door just opened, start recording or send a notification").

  • Video Compression

    H.265+

    Smart version of H.265, designed for 4K/8K surveillance. It offers very low bandwidth in static scenes, combining high image quality with significant storage space savings.

    • The standard supports approximately 50–60 days of continuous recording on a 2TB hard drive

    (Values and durations are indicative and based on standard settings. Actual performance may vary depending on resolution, frame rate, scene movement, and hardware.)
  • See all

Learn more about invoicing
Review the product
Product report

Description

Description

The BCS-L-NVR6404-A-8K-Ai2 is an IP recorder for professional surveillance systems, supporting up to 64 IP cameras and a stated configuration of 32 channels. It supports storage of up to 20 TB across 4 SATA drives, as well as archiving to USB FLASH or USB HDD.

It offers the following recording capabilities:

  • Continuous, manual, alarm, motion detection, scheduled, and AI recording.
  • AcuPick, smart object search, face recognition, people recognition, and perimeter protection.
  • Support for cameras up to 32 Mpx.

Technical specifications:

  • Type: IP Recorder
  • Channels: 64
  • Input/output/recording bandwidth: 448 Mbps (200 Mbps AI)
  • Video compression: H.265+, H.265, H.264+, H.264, MJPEG
  • Outputs: 2×HDMI 8K and 2×VGA
  • HDMI resolution: 7680×4320 / 3840×2160 / 1920×1080 / 1280×1024 / 1280×720
  • VGA resolution: 1920×1080 / 1280×1024 / 1280×720
  • Ports: 1×USB2.0, 2×USB3.0, eSATA, RS232, RS485, 2×RJ-45 10/100/1000 Mbps
  • Power supply: 100~240V AC
  • Power consumption without disks: max 13W
  • Operating conditions: -10°C~+55°C, max 93% RH
  • Housing: 1.5U
  • Dimensions (W×D×H): 440×416×76 mm
  • Users: 128
  • Alarm inputs: 16
  • Alarm outputs: 6
  • Audio input: 1
  • Audio output: 2
  • Audio compression: G.711A / G.711U / G.726 / PCM
  • Compatibility: ONVIF(S/G/T/M), support for cameras from other manufacturers
  • PTZ: 3D intelligent positioning with BCS LINE series PTZ cameras

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Type
NVR

Type

NVR
Recorder that uses IP cameras and network connection for video recording and management.
Number of Channels Outputs
64

Number of Channels Outputs

The maximum number of cameras that can be connected to and managed by the recorder
Resolution
8K
WiFi
No

WiFi

Specifies whether the device can connect wirelessly to your router (Wi-Fi)
Incoming Bandwidth
448 Mbps

Incoming Bandwidth: 448

This is the actual processing power of the recorder. It determines how much "load" (data) it can handle simultaneously from all cameras. A high number is necessary for many channels at high 4K resolution.


  • Example 1: You have 4 cameras of 5MP (each requiring ~8 Mbps). A total of ~32 Mbps is required. An NVR with 80 Mbps Incoming Bandwidth is more than enough.
  • Example 2: You have 16 cameras of 4K (each requiring ~12 Mbps). A total of ~192 Mbps is required. An NVR with 160 Mbps is not enough and will "lose" cameras or reduce their quality. Here, you need an NVR with at least 256 Mbps.
Gigabit Port
Yes

Gigabit Port

Specifies the speed of the wired network connection (LAN). "Gigabit" (1000 Mbps) is 10 times faster than standard "Fast Ethernet" (100 Mbps). It is essential for multi-channel 4K NVRs to handle the large volume of data from the cameras without delay.
Ports
HDMI, USB, VGA, e-Sata, Alarm Output, Alarm Input

Ports

HDMI
The digital output for video and audio. It is the standard way to connect the recorder to a modern TV or monitor (PC) and view your cameras in high resolution.
USB

Its main use is to connect a mouse for menu navigation and settings. Additionally, it is used to connect a USB stick (flash drive) in order to export (take a backup of) specific video clips that interest you.

VGA

An analog video output. Used to connect the recorder to older computer monitors.

e-Sata
A specialized, high-speed port that allows the connection of an external hard drive. It is mainly used in professional setups to expand the total storage (recording) capacity.
Alarm Output
Physical ports (terminals) that allow the recorder to give a "command" to external devices. For example, "As soon as I detect a person, activate an external siren or turn on the lights."
Alarm Input
Physical ports (terminals) that allow external sensors (e.g., door magnetic contact, radar) to send a "command" to the recorder (e.g., "The door just opened, start recording or send a notification").
ONVIF
Yes

ONVIF

ONVIF is a protocol that allows cameras and recorders from different manufacturers to communicate with each other.
Video Compression
H.265+

Video Compression

H.265+

Smart version of H.265, designed for 4K/8K surveillance. It offers very low bandwidth in static scenes, combining high image quality with significant storage space savings.

  • The standard supports approximately 50–60 days of continuous recording on a 2TB hard drive

(Values and durations are indicative and based on standard settings. Actual performance may vary depending on resolution, frame rate, scene movement, and hardware.)

Smart AI Detection

Human Detection
No

Human Detection

The technology recognizes human shapes in real time. Ideal for security, area monitoring, or alarms, reducing false alarms caused by other objects.
Vehicle Detection
No

Vehicle Detection

Recognizes and tracks vehicles, distinguishing them from other objects. Useful for parking, traffic management, or road surveillance.

HDD

HDD Slots
4

HDD Slots

The number of internal hard drives (SATA) that can be installed simultaneously in the recorder.
Maximum Capacity per Disk
20 TB

Maximum Capacity per Disk

The maximum size (in TB - Terabytes) of the hard drive that the device "recognizes" and supports in each slot.
Includes Hard Drive
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The BCS-L-NVR6404-A-8K-Ai2 is an IP recorder for professional surveillance systems, supporting up to 64 IP cameras and a stated configuration of 32 channels. It supports storage of up to 20 TB across 4 SATA drives, as well as archiving to USB FLASH or USB HDD.

It offers the following recording capabilities:

  • Continuous, manual, alarm, motion detection, scheduled, and AI recording.
  • AcuPick, smart object search, face recognition, people recognition, and perimeter protection.
  • Support for cameras up to 32 Mpx.

Technical specifications:

  • Type: IP Recorder
  • Channels: 64
  • Input/output/recording bandwidth: 448 Mbps (200 Mbps AI)
  • Video compression: H.265+, H.265, H.264+, H.264, MJPEG
  • Outputs: 2×HDMI 8K and 2×VGA
  • HDMI resolution: 7680×4320 / 3840×2160 / 1920×1080 / 1280×1024 / 1280×720
  • VGA resolution: 1920×1080 / 1280×1024 / 1280×720
  • Ports: 1×USB2.0, 2×USB3.0, eSATA, RS232, RS485, 2×RJ-45 10/100/1000 Mbps
  • Power supply: 100~240V AC
  • Power consumption without disks: max 13W
  • Operating conditions: -10°C~+55°C, max 93% RH
  • Housing: 1.5U
  • Dimensions (W×D×H): 440×416×76 mm
  • Users: 128
  • Alarm inputs: 16
  • Alarm outputs: 6
  • Audio input: 1
  • Audio output: 2
  • Audio compression: G.711A / G.711U / G.726 / PCM
  • Compatibility: ONVIF(S/G/T/M), support for cameras from other manufacturers
  • PTZ: 3D intelligent positioning with BCS LINE series PTZ cameras
