MW Power DIN Rail Power Supply With Power 60W 5A
DIN Rail Power Supplies

MW Power DIN Rail Power Supply With Power 60W 5A

The MW Power 12V/5A-TP switching power supply features a metal aluminum housing and is designed for installation in a 60mm electrical box. It provides a 12 VDC output, 60 W power, and 5 A current. The...

The MW Power 12V/5A-TP switching power supply features a metal aluminum housing and is designed for installation in a 60mm electrical box. It provides a 12 VDC output, 60 W power, and 5 A current. The IP66 protection safeguards it against dust and water.

  • Manufacturer Code: 12V/5A-TP
  • Rated Output Power: 60.00 W
  • Input Voltage: 100 ... 240 VAC
  • Output Voltage:...
See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

The MW Power 12V/5A-TP switching power supply features a metal aluminum housing and is designed for installation in a 60mm electrical box. It provides a 12 VDC output, 60 W power, and 5 A current. The IP66 protection safeguards it against dust and water.

  • Manufacturer Code: 12V/5A-TP
  • Rated Output Power: 60.00 W
  • Input Voltage: 100 ... 240 VAC
  • Output Voltage: 12 VDC, tolerance ± 0.5 V
  • Output Current: 5 A
  • Frequency: 50 ... 60 Hz
  • Outputs: 1 pc.
  • Protections: overload, short circuit, overvoltage, and thermal protection
  • Housing: aluminum, IP66
  • Operating Temperature: -20 °C ... 50 °C
  • Dimensions: 57 x 48 x 26 mm
  • Weight: 0.138 kg

Manufacturer

Manufacturer Details

Warnings & Safety Information
Power
60 W
Power Intensity
5 A
UPS
No

UPS

Provides voltage to the output for a limited period of time in case of power outage.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

35,90 €
14,00 €   shipping cost
