Geberit Duofix support set for shower enclosures with wall drainage. Features:

• Self-supporting construction
• Adjustable siphon inlet height
• Anti-slip foot supports
• Swiveling plates

It is compatible with Geberit grates with numbers 154.335 and 154.338. The sealing membrane is pre-installed around the entire perimeter with a width of 100 mm.

Technical specifications:

• Manufacturer: Geberit
• Series: DUOFIX
• Manufacturer code: 111.593.00.1
• Width: 500 mm
• Use: Shower enclosure, wall drainage
• Siphon height: 30 mm
• Minimum floor height at the inlet: 65 mm
• Finish thickness: 10–40 mm
• Drain connection: Left or right
• Frame hole diameter: 9 mm
• Coating: Powder
• Maximum flow rate: 0.4 l/s
