Male InLine D-Sub 9 connector with spring clamp terminal and screw locking, model 92501B. Installation is carried out without soldering or crimping. The screw locking helps ensure stability under vibration conditions.
Suitable for:
Type: D-Sub 9 male
Dimensions: 51 × 31.5 × 18 mm (L × W × H)
Insulation: EVA
Insulation resistance: ≥ 10 MΩ
Rated current: 0.8 A per pin
Maximum operating voltage: 100 V between two signals
Conductor range: 14–22 AWG
Operating temperature: –10°C to +70°C
Screw locking: 5 mm pitch
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
