Elektro Plast Electrical Panel Support Rail 48.317
Electrical Panel Accessories

Elektro Plast Electrical Panel Support Rail 48.317

Three-pole AL/CU Elektro-Plast distribution block for 3x16 mm² conductors, suitable for flat mounting or mounting on a 35 mm TH rail.

  • Screw electrical connection
  • Plastic housing in yellow-green
  • Type:...

Three-pole AL/CU Elektro-Plast distribution block for 3x16 mm² conductors, suitable for flat mounting or mounting on a 35 mm TH rail.

  • Screw electrical connection
  • Plastic housing in yellow-green
  • Type: distribution block
  • Rated voltage (Un): 400 V AC
  • Rated current (In): 80 A
  • Operating temperature: from -25°C to +85°C
  • Degree of protection: IP20
  • Standard: IEC/EN...
See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

Three-pole AL/CU Elektro-Plast distribution block for 3x16 mm² conductors, suitable for flat mounting or mounting on a 35 mm TH rail.

  • Screw electrical connection
  • Plastic housing in yellow-green
  • Type: distribution block
  • Rated voltage (Un): 400 V AC
  • Rated current (In): 80 A
  • Operating temperature: from -25°C to +85°C
  • Degree of protection: IP20
  • Standard: IEC/EN 60947-7-1
  • Colour: grey
  • Width/pitch size: 42.5 mm
  • Levels: 1
  • Terminals per level: 6
  • Rated current of feed-through terminals: 75 A
  • Connectable conductor cross-section: from 1.5 mm² to 16 mm²
  • Connection: screw

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Support Rail

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

8,90 €
14,00 €   shipping cost
