Elektro Plast Electrical Panel Support Rail 48.336

Three-pole AL/CU Elektro-Plast distribution block

The three-pole distribution block is suitable for surface mounting or mounting on a 35 mm TH rail. The plastic housing features screw terminals and...

Three-pole AL/CU Elektro-Plast distribution block

The three-pole distribution block is suitable for surface mounting or mounting on a 35 mm TH rail. The plastic housing features screw terminals and side-entry connections.

  • Conductor cross-section: 2.5 mm² to 35 mm²
  • Rated voltage (Un): 400 V AC
  • Rated current (In): 125 A
  • Rated connector current: 120 A
  • ...
See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

Three-pole AL/CU Elektro-Plast distribution block

The three-pole distribution block is suitable for surface mounting or mounting on a 35 mm TH rail. The plastic housing features screw terminals and side-entry connections.

  • Conductor cross-section: 2.5 mm² to 35 mm²
  • Rated voltage (Un): 400 V AC
  • Rated current (In): 125 A
  • Rated connector current: 120 A
  • Operating temperature: -25°C to +85°C
  • Degree of protection: IP20
  • Standard: IEC/EN 60947-7-1
  • Poles: 3
  • Width/module size: 45 mm
  • Levels: 1
  • Terminals per level: 6
  • Housing material: yellow-green plastic*
  • Connector colour: grey

*This wording is part of a name or functional description and does not constitute a claim of a positive environmental impact.

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Support Rail

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
