SilentiumPC IP20 LED Power Supply 960W with 24V Output Voltage
LED Power Supplies

SilentiumPC IP20 LED Power Supply 960W with 24V Output Voltage

SilentiumPC KDR 96024 switching power supply for DIN rail, with the following features:

  • Regulated output: 24VDC
  • Power rating: 960W
  • Maximum current: 40A
  • AC input range: 180–264VAC
  • DC input range: 120–...

SilentiumPC KDR 96024 switching power supply for DIN rail, with the following features:

  • Regulated output: 24VDC
  • Power rating: 960W
  • Maximum current: 40A
  • AC input range: 180–264VAC
  • DC input range: 120–370VDC
  • Efficiency: 94%
  • Protection rating: IP20
  • Connection: screw terminal
  • Dimensions: 110 mm x 125.2 mm x 150 mm
  • Operating temperature: -30 to +70 °C
  • ...
See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

SilentiumPC KDR 96024 switching power supply for DIN rail, with the following features:

  • Regulated output: 24VDC
  • Power rating: 960W
  • Maximum current: 40A
  • AC input range: 180–264VAC
  • DC input range: 120–370VDC
  • Efficiency: 94%
  • Protection rating: IP20
  • Connection: screw terminal
  • Dimensions: 110 mm x 125.2 mm x 150 mm
  • Operating temperature: -30 to +70 °C
  • Protections: thermal, short-circuit, overload and overvoltage
  • Cooling: airflow
  • Modular: yes
  • LED indicator: yes, DC-OK
  • Standards: EN55032, EN55035, EN61000-3-2, EN61000-3-3, EN 62368-1

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Rail
Output (DC)
24 V
Power
960 W
Waterproofing
IP20

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

492,90 €
14,00 €   shipping cost
