Description
Specifications
Belden H155A02.00500 coaxial cable with an impedance of 50 Ohm, suitable for antenna communications, wireless microphones, radiotelephones, GPS and RFID. It features a bare copper (BC) 16 AWG conductor, PE insulation and an LSZH jacket with low smoke emissions and zero halogen content.
- Outer shielding: Duofoil® and 80% tinned copper braid
- Jacket diameter: 5.4 mm
- Operating temperature: -30°C to +70°C
- Attenuation: 2.5 dB/100 m at 5 MHz, 6.9 dB/100 m at 50 MHz, 9.1 dB/100 m at 100 MHz, 18 dB/100 m at 400 MHz and 29.6 dB/100 m at 1000 MHz
- Maximum tensile force: 100 N (22 lbf)
- CPR compliance: Euroclass Dca-s1,d1,a1
- EU marking: CE Mark
- Type
- SMA
- Terminal A
- -
- Terminal B
- -
- Length
- 500 m
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
