- Final amplifier 2X525W/4Ω/1550W Bridge/4Ω.
- DriveCore2 inputs 2 x XLR.+1/4 inch, + RCA, outputs binding post+speakon
- Features next-generation DSP with Crossover (HP+BP+LP)
- New LED indicator control and XMAX Limiters
- New larger LCD screen
- Selectable input sensitivity, time out mode, Security lock, System reset, Remote power trigger
- 2U rack
- Weight 3.9 kg
Specifications:
- Input Impedance: 20kΩ, 10kΩ
- Depth (cm): 19.6
- AC Line Voltage and Frequency Configurations Available:(+/- 10%) 220 VAC 50 Hz
- Height (cm): 8.9
- Weight (Kg): 3.9
- Rack Installation Possible: Yes
- Order Quantity: 1
- Channels: 2
- Power Output W/4Ω: 525
- Signal to Noise Ratio (dB): >103 dB
- Total Harmonic Distortion (THD) (full rated power, 20Hz to 20kHz) <: <0.5%, 20 Hz - 20 kHz
- Frequency Response (at 1W, 4/8Ω) (dB) ±: 20 Hz - 20 kHz, +0/-1 dB (at 1 watt)
- Amplifier Type: Attribute9977
- Catalog: Professional
- Crosstalk (below rated power) 20Hz to 1kHz > (db): >85 dB, >55 dB
- Load Impedance: Ohm
- Power Output W/8Ω: 300
- Power Output W/Bridge Mode/8Ω: 1050
- Voltage Gain (dB): 31 dB
- Input Sensitivity: 1.4Vrms (for full rated power at 4 ohms)
- Width (cm): 48.3
Technical Specifications
- Amplifier Type
- PA Amplifier
- Type
- Power Amplifier
- Channels
- 2
- Power (8Ω)
- 300 watt / channel
- Power (4Ω)
- 525 watt / channel
- Class
- D
- Weight
- 3.9 kg
Additional Specifications
- Radio
- No
- Cooling system
- No
Connectivity
- RCA
- Yes
- XLR
- Yes
- Mini Jack (3.5mm)
- No
- Jack (6.3mm)
- Yes
- USB
- No
- Ethernet
- No
- Bluetooth
- No
- Mic In
- No
Dimensions
- Width
- 483 mm
- Height
- 89 mm
- Length
- 196 mm
