- UPS topology: Line-Interactive
- Output power capacity (VA): 0.7 kVA
- Output power: 420 W
- Waveform: Sine
- Input operating voltage (min): 165 V
- Input operating voltage (max): 290 V
- Input frequency: 50/60 Hz
- Output operating voltage (min): 220 V
- Output operating voltage (max): 240 V
- Output frequency: 50/60 Hz
- Automatic Voltage Regulation (AVR): YES
- Surge energy rating: 150 J
- Transfer time: 4 ms
- Heat dissipation: 71 BTU/h
- Noise filtering (EMI/RFI): YES
- Surge protection: YES
- Surge protection features: Fax, Modem, Network, Telephone
- Power protection features: Short circuit
- Audible alarms: YES
- Audible alarm functions: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features:
- UPS topology: Line-Interactive
- Output power capacity (VA): 0.7 kVA
- Output power: 420 W
- Waveform: Sine
- Input operating voltage (min): 165 V
- Input operating voltage (max): 290 V
- Input frequency: 50/60 Hz
- Output operating voltage (min): 220 V
- Output operating voltage (max): 240 V
- Output frequency: 50/60 Hz
- Automatic Voltage Regulation (AVR): YES
- Surge energy rating: 150 J
- Response time: 4 ms
- Heat dissipation: 71 BTU/h
- Noise filtering (EMI/RFI): YES
- Surge protection: YES
- Surge protection features: Fax, Modem, Network, Telephone
- Power protection features: Short circuit
- Audible alarms: YES
- Audible alarm functions: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Connectivity:
- AC outlet types: Type F
- Number of AC outlets: 8 AC outlet(s)
- USB port: YES
- Number of USB 2.0 ports: 1
- USB port type: USB Type-A
- Modem (RJ-11) ports: 2
- Number of Ethernet LAN (RJ-45) ports: 2
Battery:
- Battery technology: Sealed Lead Acid (VRLA)
- Battery voltage: 230 V
- Number of batteries supported: 1
- Typical backup time at full load: 1.5 minutes
- Typical backup time at half load: 9 minutes
- Battery recharge time: 8 hours
- Battery replacement head: RBP0083
Design:
- Form factor: Desktop
- Product color: Black
- Housing material: Plastic
- Cable length: 1.5 m
- Display type: LED
- LED indicators: YES
Environmental conditions:
- Operating temperature range: 0 - 40°C
- Storage temperature limits: -20 - 50°C
- Operating humidity range: 0 - 90%
- Non-operating humidity: 0 - 90%
- Operating altitude: 0 - 3000 m
Technical details:
- Sustainability compliance: YES
- Sustainability certificates: CE, EAC, RoHS
Weight and dimensions:
- Width: 166 mm
- Depth: 288 mm
- Height: 118 mm
- Weight: 5300 g
- Package width: 158 mm
- Package depth: 325 mm
- Package height: 230 mm
- Package weight: 6050 g
Other features:
- Number of phases: 1
Features:
- UPS topology: Line-Interactive
- Output power capacity (VA): 0.7 kVA
- Output power: 420 W
- Waveform: Sine
- Input operating voltage (min): 165 V
- Input operating voltage (max): 290 V
- Input frequency: 50/60 Hz
- Output operating voltage (min): 220 V
- Output operating voltage (max): 240 V
- Output frequency: 50/60 Hz
- Automatic Voltage Regulation (AVR): YES
- Surge energy rating: 150 J
- Transfer time: 4 ms
- Heat dissipation: 71 BTU/h
- Noise filtering (EMI/RFI): YES
- Surge protection: YES
- Surge protection features: Fax, Modem, Network, Telephone
- Power protection features: Short circuit
- Audible alarms: YES
- Audible alarm functions: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Connectivity:
- AC plug types: Type F
- Number of AC outlets: 8 AC output(s)
- USB port: YES
- Number of USB 2.0 ports: 1
- USB port type: USB Type-A
- Modem ports (RJ-11): 2
- Number of ethernet LAN ports (RJ-45): 2
Battery:
- Battery technology: Sealed Lead Acid (VRLA)
- Battery voltage: 230 V
- Number of supported batteries: 1
- Typical backup time at full load: 1.5 minutes
- Typical backup time at half load: 9 minutes
- Battery recharge time: 8 hours
- Battery head replacement: RBP0083
Design:
- Form factor: Desktop
- Product color: Black
- Enclosure material: Plastic
- Cable length: 1.5 m
- Display type: LED
- LED communication indicators: YES
Environmental conditions:
- Operating temperature range: 0 - 40°C
- Storage temperature limits: -20 - 50°C
- Operating humidity range: 0 - 90%
- Non-operating humidity: 0 - 90%
- Operating altitude: 0 - 3000 m
Weight and dimensions:
- Width: 166 mm
- Depth: 288 mm
- Height: 118 mm
- Weight: 5300 g
- Package width: 158 mm
- Package depth: 325 mm
- Package height: 230 mm
- Package weight: 6050 g
Dimensions
- Type
- (VI) Line-Interactive
- Power (VA)
- 700 VA
- Power (Watt)
- 420 W
- Size
- Compact
- Output Waveform
- Modified Sine Wave,Modified sinewave
- Battery Duration (Half Load)
- 9 min
- Battery Duration (Full Load)
- 1.5 min
- Noise Level
- -
- Display Screen
- Digital Display
Connectivity
- USB
- Yes
- AC outlets
- 8
- Plug Type
- Schuko
- Extra Ports
- RJ-11, RJ-45
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
