The Host Memory Buffer (HMB) function uses the PCI Express Direct Memory Access (DMA) to allow SSDs to use part of the DRAM memory in the computer system, instead of requiring the SSD to carry its own DRAM.
Description
Specifications
This drive dramatically improves the responsiveness of your existing system with incredible boot, load, and transfer times compared to mechanical hard drives.
Host Memory Buffer (HMB)
The Host Memory Buffer (HMB) function uses the PCI Express Direct Memory Access (DMA) to allow SSDs to use part of the DRAM memory in the computer system, instead of requiring the SSD to carry its own DRAM.
Breaking the Barriers of SATA Limitations
Outstanding Performance
- The GIGABYTE M.2 PCIe SSD provides performance for your daily computing tasks, featuring the best controller and NAND flash.
- Sequential read speeds up to 1200 MB/s.
- Sequential write speeds up to 800 MB/s.
- The GIGABYTE M.2 PCIe SSD offers you a faster data transfer experience compared to the SATA 2.5" SSD.
SSD Tool Box
The recently updated SSD Tool Box is an application that helps users monitor the status of the SSD, providing general information such as model name, FW version, health status, drive optimization, and also detects the sensor temperature.
Additionally, users can erase all data with the Secure Erase function. You can download the SSD Tool Box from Support.
Product Details
- Capacity
- 256 GB
- Communication Protocol
- PCI Express 3.0
- NVMe
- Yes
- Heatsink
- No
- Compatible with PlayStation 5
- No
- Device Group
- Laptops
Dimensions
- Form Factor
- M.2 (Type 2280)
Performance
- Read Speed
- 1700 MB/s
- Write Speed
- 1100 MB/s
- Maximum 4KB Random Write
- 250000 IOPS
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
