Management Features
- Switch Type: Managed
- Layer Switching: L2
- Quality of Service (QoS) Support: NO
- Internet Management: NO
- MIB Support: NO
Connectivity
- Number of Basic Switching Ethernet Ports: RJ-468
- Type of Basic Switching Ethernet Ports: RJ-45 Gigabit Ethernet (10/100/1000)
- Number of SFP Module Slots: 2
- Optical Channel Ports: 2
- Optical Fiber Slot: SFP
- Console Port: RJ-45
Networking
- Network Standard: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G Support: NO
- Copper Network Cabling Technology: 1000BASE-T, 1000BASE-TX, 10BASE-T
- Port Mirroring: NO
- Flow Control Support: NO
- Link Aggregation: NO
- Broadcast Storm Control: NO
- Rate Limiting: NO
- Spanning Tree Protocol: NO
- VLAN Support: NO
- Virtual LAN Functions: MAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Voice VLAN
- Number of VLANs: 4000
Optical Fiber
- Optical Fiber Ethernet Cabling Technology: 1000BASE-X, 100BASE-FX
- Fiber Type: Multi-mode
Data Transfer
- Address Table Size: 8000 entries
- Routing/Switching Capacity: 20 Gbit/s
- Forwarding Rate: 14.88 Mpps
- Number of Queues: 4
- Jumbo Frames Support: NO
- Jumbo Frames: 9000
- Packet Buffer Memory: 4.1 MB
Security
- DHCP Functions: DHCP client, DHCP snooping, DHCPv6 client, DHCPv6 snooping
- Access Control List (ACL): NO
- IGMP Snooping: NO
- Security Algorithm Support: SNMP, SSH, SSH-2
- MAC Address Filtering: NO
- SSH/SSL Support: NO
- BPDU Filtering/Protection: NO
Multicast Functions
- Multicast Support: NO
Design
- Product Color: Black
- Communication LED Indicators: Link, PoE, Power
- Certifications: ISVCE, FCC, RoHS
Performance
- Compatible Operating Systems: Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
- Fanless: NO
- Recommended System Requirements: Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
Power Management
- Power Source: AC
- Power Supply Included: NO
- AC Input Voltage: 100 - 240V
- AC Input Frequency: 50 - 60Hz
- Power Consumption (max): 75.3W
- Power over Ethernet (PoE) Technology:
- PoE Power Supply: NO
- Power over Ethernet Plus (PoE+) Port Count: 8
- Total Power over Ethernet (PoE) Budget: 58W
Environmental Conditions
- Operating Temperature Range: 0 - 40°C
- Storage Temperature Limits: -40 - 70°C
- Operating Humidity Range: 10 - 90%
- Non-operating Humidity: 5 - 90%
Weight and Dimensions
- Width: 209 mm
- Depth: 126 mm
- Height: 26 mm
Package Contents
- Cables Included: AC
- Quick Start Guide: NO
- Package Width: 315 mm
- Package Depth: 240 mm
- Package Height: 70 mm
Logistics Data
- Harmonized System (HS) Code: 85176990
Network Specifications
- Type
- Managed
- Layer
- L2
- PoE
- Yes
Technical Specifications
- Ethernet connections
- 8 Port
- Ethernet Speed
- 100 Mbps, 1000 Mbps
- SFP connections
- 2 Port
- Switching Speed
- 20 Gbps
- MAC Address Table
- 8000 entries
- Rack mounting
- No
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
