- The smallest powerful 12 V tool package with impact drilling function
- Newly developed 2-speed planetary gearbox for powerful screwdriving and drilling in wood and metal as well as impact drilling in masonry
- High-quality Auto-Lock 10 mm chuck
- Practical battery charge status indicator: Always informs about the available battery power
- Bosch Electronic Cell Protection (ECP): Protects the battery from overload, overheating, and deep discharge
- Integrated LED light for illuminating the work area even in dark places
- Motor brake for precise work during continuous screwdriving
At a glance
- The smallest powerful 12 V tool package with impact drilling function
- Newly developed 2-speed planetary gearbox for powerful screwdriving and drilling in wood and metal as well as impact drilling in masonry
- High-quality Auto-Lock 10 mm chuck
- Practical battery charge status indicator: Always informs about the available battery power
- Bosch Electronic Cell Protection (ECP): Protects the battery from overload, overheating, and deep discharge
- Integrated LED light for illuminating the work area even in dark places
- Motor brake for precise work during continuous screwdriving
Functions
- More speeds
- Impact drilling
- Right and left rotation
- Electronic system
- Auto-Lock
- Soft grip
- Light
Specifications
- Torque, max. (hard screwdriving applications): 30 Nm
- Torque, max. (soft screwdriving applications): 15 Nm
- No-load speed (1st gear/2nd gear): 0 - 380 / 0 - 1,300 rpm
- Max. impact rate: 19,500 bpm
- Chuck clamping range, min./max.: 1 / 10 mm
- Drill spindle thread: 1/2"
- Battery voltage: 12V
- Battery capacity: 2 Ah
- Weight with battery: 1 kg
- Torque settings: 20+1
- Length: 189.0 mm
- Height: 182.0 mm
- Cell type: Lithium-ion
- Drilling diameter in wood, max.: 19 mm
- Drilling diameter in steel, max.: 10 mm
- Drilling diameter in masonry, max.: 10 mm
- Screw diameter, max.: 7 mm
Package Contents
- Set of 25 screwdriver bits
- Set of 7 wood drill bits
- Set of 7 metal drill bits
- 1 battery 2.0 Ah Li-Ion
- 1 battery 4.0 Ah Li-Ion
- Fabric Case
- Charger GAL 12V-20
Product Guides
Product Details
- Type
- Drill Driver
- Power Source
- Battery
- Brushless
- No
Battery Features
- Number of Batteries
- 2
- Battery Voltage
- 12 V
- Battery Capacity
- 2 Ah
- Secondary Battery Charge Ah
- 4 Ah
- Compatible Battery Type
- Bosch GBA 12V, Bosch GBA 10.8V
Drilling Abilities
- Steel Ø
- 10 mm
- Wood Ø
- 19 mm
- Cement Ø
- 10 mm
Features & Functions
- Maximum Motor Speed
- 1300 rpm
- Speed Adjustment
- Yes
- Maximum Torque
- 30 Nm
- Maximum Number of Hits
- 19500 bpm
- Torque Adjustment
- Yes
- Percussive
- Yes
- Angle
- No
- Interchangeable Head
- No
- Reception
- Quick Change
- Maximum Chuck Diameter
- 10 mm
- Weight (with Battery)
- 1000 gr
Extra Features
- Carrying Case
- Soft Case
- Handle Included
- No
- Integrated Light
- Yes
