- With 189 mm, the most compact design in its category for ideal handling, especially for drilling and screwing tasks overhead and in tight spaces.
- Recently developed 2-speed planetary gearbox for powerful screwing and drilling tasks in wood and metal, as well as impact drilling tasks in masonry.
- Bosch Electronic Cell Protection (ECP): Protects the battery from overloading, overheating, and deep discharge.
- Motor brake for precise work during continuous screwing.
- High-quality Auto-Lock 10 mm chuck.
- Integrated LED light for illuminating the work area even in dark spots.
At a glance
- With 189 mm, the most compact design in its category for ideal handling, especially for drilling and screwing tasks overhead and in tight spaces.
- Recently developed 2-speed planetary gearbox for powerful screwing and drilling tasks in wood and metal, as well as impact drilling tasks in masonry.
- Bosch Electronic Cell Protection (ECP): Protects the battery from overloading, overheating, and deep discharge.
- Motor brake for precise work during continuous screwing.
- High-quality Auto-Lock 10 mm chuck.
- Integrated LED light for illuminating the work area even in dark spots.
Drill Diameter
- Drilling diameter in wood, max. 19 mm
- Drilling diameter in steel, max. 10 mm
- Drilling diameter in masonry, max. 10 mm
- Screw diameter, max. 7 mm
Specifications
- Torque, max. (hard screwdriving applications) 30 Nm
- Torque, max. (soft screwdriving applications) 13 Nm
- No-load speed (1st gear/2nd gear) 0 – 380 / 0 – 1,300 min-1
- Max. impact rate 19,500 min-1
- Chuck clamping range, min./max. 1 / 10 mm
- Drill spindle thread 1/2"
- Battery voltage 10.8 V
- Weight with battery 1 kg
- Torque settings 20+1
- Length 189.0 mm
- Height 175.0 mm
Product Guides
Product Details
- Type
- Drill Driver
- Power Source
- Battery
- Brushless
- No
Battery Features
- Number of Batteries
- 0
- Battery Voltage
- 12 V
- Secondary Battery Charge Ah
- 2 Ah
- Compatible Battery Type
- Bosch GBA 12V, Bosch GBA 10.8V
Drilling Abilities
- Steel Ø
- 10 mm
- Wood Ø
- 19 mm
- Cement Ø
- 10 mm
Features & Functions
- Maximum Motor Speed
- 1300 rpm
- Speed Adjustment
- Yes
- Maximum Torque
- 30 Nm
- Maximum Number of Hits
- -
- Torque Adjustment
- Yes
- Percussive
- Yes
- Angle
- No
- Interchangeable Head
- No
- Reception
- Quick Change
- Maximum Chuck Diameter
- 10 mm
- Net Weight
- 825 gr
- Weight (with Battery)
- 1000 gr
Extra Features
- Carrying Case
- Hard Case
- Handle Included
- No
- Integrated Light
- Yes
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
