The G12 GC achieves 80 PLUS Gold certification with 90% efficiency at 50% system load.
The G12 GC series is available in the standard ATX Form Factor and in wattages that are most common for a computer system.
The Seasonic G12 GC-Series achieves the 80 PLUS Gold standard by providing at least 87%, 90%, and 87% energy consumption efficiency at 20%, 50%, and 100% operational loads, respectively. This efficiency, combined with active power factor correction, allows the G12 GC series power supplies to reduce energy waste, which translates into cost savings on energy costs for its users.
Beyond being efficient, the G12 GC units utilize the LLC resonant converter design and the industry's leading Smart and Silent Fan Control (S2FC).
80 PLUS GOLD
The G12 GC achieves 80 PLUS Gold certification with 90% efficiency at 50% system load.
Smart / Silent Fan Control
The intelligent temperature control circuit is designed to find the optimal balance between the need to cool the components and the need to operate the power supply in the quietest possible manner.
Protection Technologies
The Seasonic G12 GC protects your PC from over power (OPP), over voltage (OVP), under voltage (UVP), over current (OCP), over temperature (OTP), and short circuit (SCP).
Loads
- Operating Voltage: 100-240V
Maximum Load:
- Line Current +3.3 V: 15A
- Line Current +5 V: 15A
- Line Current +12 V: 45A
- Line Current -12 V: 0.3A
- Line Current +5 Vsb: 3A
Wiring
- 1x ATX 20 + 4-pin motherboard power connector.
- 1x EPS/ATX12V 8 Pin (4+4) CPU power connector
- 1x PCIe 6+2 graphics card power connector, to take advantage of modern GPUs in combination with your PC's capabilities
- 6x SATA power connectors for SSD or HDD hard drives
- 3x Molex 4-pin connectors for connecting additional peripherals
Compatibility with Graphics Cards & Processors
Nvidia
AMD
Product Guides
Dimensions
- Power
- 550 W
- Size
- ATX
- Modularity
- Full Wired
- Certification
- 80 Plus Gold
- Fan Dimension
- 120 mm
- Power Protection
- Over Current Protection (OCP), Over Power Protection (OPP), Over Voltage Protection (OVP), Short Circuit Protection (SCP)
- Color
- Black
ATX Version
- ATX 3.1
- -
