The TP-LINK TL-SG108 v8 switch connects devices via eight Gigabit Ethernet RJ45 ports, with automatic 10/100/1000 Mbps speed negotiation and Auto MDI/MDIX. It supports IEEE 802.3x flow control, QoS and IGMP Snooping for managing network traffic. It features Plug and Play operation, a fanless design, and adjusts power consumption according to link status and cable length.
- Type: Unmanaged Layer 2 switch
- Ports: 8 RJ45 Gigabit Ethernet, 10/100/1000 Mbps
- Port features: Auto-negotiation and Auto MDI/MDIX
- Standards and protocols: IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.1p
- Traffic management: QoS IEEE 802.1p/DSCP and IGMP Snooping
- Flow control: IEEE 802.3x
- Transmission method: Store and Forward
- Packet forwarding rate: 11.9 Mp/s
- MAC address table: 4,000 entries
- Buffer memory: 1.5 Mb
- Jumbo frames: 16 KB
- Energy savings: Up to 82%
- Power supply: External power adapter, 9 V DC / 0.6 A output
- Maximum power consumption: 3.31 W at 220 V / 50 Hz
- Heat dissipation: 11.29 BTU/h
- LED indicators: Power, link and activity for each RJ45 port
- Enclosure: Desktop, fanless
- Dimensions: 158 × 101 × 25 mm
- Operating temperature: 0 to 40 °C
- Storage temperature: -40 to 70 °C
- Operating humidity: 10% to 90%, non-condensing
- Storage humidity: 5% to 90%, non-condensing
- Certifications: CE, FCC, RoHS
- Package contents: Switch, power adapter and user manual
Network Specifications
- Type
- Unmanaged
- Layer
- L2
- PoE
- No
Technical Specifications
- Ethernet connections
- 8 Port
- Ethernet Speed
- 1000 Mbps, 100 Mbps
- MAC Address Table
- 4000 entries
- Rack mounting
- No
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
